Car Wiring Diagrams for Headlight circuit, with drl for Honda CR-V I (1995-1999)

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE COMBINATION LIGHT SWITCH DAYTIME RUNNING LIGHTS RESISTOR DIMMER SWITCH HI LO FLASH- TO- PASS SWITCH OFF ON FOG LIGHT ON INDICATOR FOGLIGHT RELAY (BEHIND LEFT SIDE OF DASH PANEL) FOGLIGHT SWITCH FOGLIGHTS IN-LINE FUSE (BEHIND LEFT SIDE OF DASH PANEL) FROM HEADLIGHT SWITCH (DIAGRAM 1 OF 1) GAUGE ASSEMBLY GRN WIRE GRN/RED WIRE GROUND IGNITION BRAKE SYS IND CTRL HDLT CTRL BATTERY HEAD OFF HEAD PARK PARK HEADLIGHT FUSE 48 HEADLIGHT SWITCH HIGH BEAM INDICATOR HOT AT ALL TIMES HOT IN ON INSTRUMENT CLUSTER SYSTEM L HEADLIGHT HIGH BEAM FUSE 5 L HEADLIGHT LOW BEAM FUSE 22 LEFT FOGLIGHT LEFT HEADLIGHT LIGHTS ON INPUT NCA WIRE OFF OFF ON OPTION FUSE 54 PARK BRAKE IN PARKING BRAKE SWITCH R HEADLIGHT LOW BEAM FUSE 21 R HEADLIGHT HIGH BEAM FUSE 4 RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FOGLIGHT RIGHT HEADLIGHT RUNNING LIGHT RELAY FUSE 18 RUNNING LIGHTS FUSE 20 TO DRL CONTROL UNIT (DIAGRAM 1 OF 1) UNDERDASH FUSE/RELAY BOX (LEFT OF STEERING COLUMN) UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPT) WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
