Honda CR-V I (1995-1999) actuator ctrl wiring diagram
This page shows the only wiring diagram for the component.actuator ctrl, which is found in the car Honda CR-V I (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
actuator ctrl wiring diagram (1 of 1)
1998 MODELS W/ A/T
ACTUATOR CTRL
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
BRAKE SWITCH INPUT
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CABLE REEL (TOP OF STEERING COLUMN)
CLUTCH PEDAL SWITCH (ON CLUTCH PEDAL SUPPORT)
CRS
CRUISE CONTROL ACTUATOR (ON LEFT SIDE OF ENGINE COMPARTMENT)
CRUISE CONTROL DIMMING CIRCUIT
CRUISE CONTROL FUSE 14
CRUISE CONTROL INDICATOR LIGHT
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL MAIN SWITCH LIGHT
CRUISE CONTROL SET/ RESUME SWITCH
CRUISE CONTROL UNIT (BEHIND LEFT KICK PANEL)
CRUISE ON INPUT
GAUGE ASSEMBLY
GRN WIRE
GRN/WHT WIRE
GROUND
GRY WIRE
HORN RELAY (BEHIND LEFT KICK PANEL)
HORN, STOP FUSE 52
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
INDICATOR LIGHT CONTROL
INSTRUMENT CLUSTER SYSTEM (SPEEDOMETER)
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
METER FUSE 25
NCA WIRE
ON INDICATOR
ON OFF
PNK A/T GEAR POSITION SWITCH (ON LOWER REAR OF TRANSAXLE) WIRE
PNK A/T WIRE
PNK DISENGAGE INPUT WIRE
PNK M/T WIRE
PNK WIRE
POWER INPUT
POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT KICK PANEL)
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RESUME/ ACCEL SIG INPUT
RESUME/ ACCEL SWITCH
SAFETY SOLENOID VENT SOLENOID
SET/ DECEL SWITCH
SET/DECEL SIG INPUT
STEERING WHEEL)
UNDERDASH FUSE/RELAY BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT)
VACUUM SOLENOID
VEHICLE SPEED INPUT
VEHICLE SPEED OUTPUT
VEHICLE SPEED SENSOR (VSS) (ON TOP LEFT OF TRANSAXLE)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Cruise control circuit -> ACTUATOR CTRL
