Electric parking brake circuit for Honda Clarity II (2016-2021)
Electric parking brake circuit
BLK WIRE
BODY CONTROL MODULE
BRAKE HOLD SWITCH
BRAKE SYSTEM IND (AMBER)
BRAKE SYSTEM IND (RED) WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRIC
ELECTRIC PARKING BRAKE SWITCH (IN CENTER CONSOLE)
ELECTRIC PLUG-IN HYBRID
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 34
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
JOINT 18 (ELECTRIC) JOINT 19 (PLUG-IN HYBRID)
LEFT ACTUATOR
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PLUG-IN HYBRID
PNK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/WHT WIRE
RED WIRE
RELAY ENERGIZED
RIGHT ACTUATOR
UNDER-DASH FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
YEL WIRE
