Horn circuit for Honda Clarity II (2016-2021)
Horn circuit
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BLK WIRE
BODY CONTROL MODULE
CABLE REEL
ELECTRIC PLUG-IN HYBRID
FUSE 20
HORN (HIGH)/ SECURITY HORN
HORN (LOW)
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES
JOINT 40 (PLUG-IN HYBRID) JOINT 36 (ELECTRIC)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL/BLK WIRE
PPL/GRY WIRE
PPL/LT GRN WIRE
RED WIRE
RELAY CIRCUIT BOARD
SECURITY HORN RELAY
