1.5l, computer data lines circuit for Honda Clarity II (2016-2021)
1.5l, computer data lines circuit (1 of 4)
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL UNIT
CONTROL UNIT)
DATA LINK CONNECTOR (DLC)
FRONT SEAT HEATER CONTROL UNIT
FUSE 21
FUSE 7
HOT AT ALL TIMES
JOINT 10
JOINT 12
JOINT 13
JOINT 19
JOINT 9
LT BLU WIRE
LT GRN WIRE
OPTIONAL CONNECTOR A
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL/BRN WIRE
PPL/RED WIRE
RED WIRE
RELAY ENERGIZED
SRS UNIT
TELEMATICS CONTROL UNIT
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
1.5l, computer data lines circuit (2 of 4)
1.5l, computer data lines circuit (3 of 4)
ACOUSTIC VEHICLE ALERTING CONTROL UNIT
ACTIVE NOISE CANCELLATION UNIT
BATTERY CHARGE CONTROL MODULE (LEFT SIDE OF DASH)
BLU WIRE
BRN WIRE
ELECTRIC COOLANT HEATER
GAUGE CONTROL MODULE
GRN WIRE
JOINT 21
JOINT 22
JOINT 23
JOINT 24
JOINT 25
JOINT 26
JOINT 34
JOINT 35
LT BLU WIRE
LT GRN WIRE
MILLIMETER WAVE RADAR
MULTIPURPOSE CAMERA UNIT
PARK PAWL ACTUATOR DRIVER UNIT
PCU
PNK WIRE
PPL/BRN WIRE
PPL/LT GRN WIRE
RED WIRE
SBW SHIFTER CONTROL MODULE
WHT WIRE
1.5l, computer data lines circuit (4 of 4)
BATTERY CONDITION MONITOR MODULE A
BATTERY CONDITION MONITOR MODULE B
BLU WIRE
BRN WIRE
DC-DC CONVERTER
ELECTRIC SERVO BRAKE CONTROL UNIT
EPS CONTROL UNIT
GRN WIRE
IPU JUNCTION 2
JOINT 36
JOINT 37
LT BLU WIRE
LT GRN WIRE
PCM
PNK WIRE
PPL/BRN WIRE
PPL/LT GRN WIRE
RED WIRE
VSA MODULATOR CONTROL UNIT
WHT WIRE
