Instrument illumination circuit, sedan for Honda Civic XI (2021-2024)

0) OFF 1) PARK 2) AUTO 3) HEAD AUDIO REMOTE- HFL SWITCH B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BODY CONTROL MODULE CENTER CONSOLE LIGHT CENTER JUNCTION BOX G COMBINATION LIGHT SWITCH COMPUTER DATA LINES SYSTEM DASHBOARD WIRE HARNESS JUNCTION BOX G DRIVER'S JUNCTION BOX B FUSE HOLDER A GAUGE CONTROL MODULE GLOVE BOX LIGHT GRN WIRE GRY WIRE HEADLIGHT SWITCH HOT AT ALL TIMES LT BLU WIRE PNK WIRE PPL RED WIRE TAN WIRE UNDER-HOOD FUSE/RELAY BOX WHT WIRE

BLU WIRE CLIMATE CONTROL SWITCH CRUSIE CONTROL/ ACC COMBINATION SWITCH DASH LIGHT BRIGHTNESS CONTROL SWITCH DRIVER MODE/IDLE STOP OFF SWITCH ELECTRIC PARKING BRAKE/AUTOMATIC BRAKE HOLD SWITCH FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR GRN WIRE GRY WIRE HAZARD WARNING SWITCH HOT AT ALL TIMES LT BLU WIRE RED WIRE RIGHT END OF DASH) ROOF MODULE) SHIFT POSITION INDICATOR SRS UNIT THERMAL JOINT 5 THERMAL JOINT 6 UNDER-DASH FUSE/RELAY BOX USB PORT HOLDER VSA OFF SWITCH/ SAFETY SUPPORT SWITCH WHT WIRE
