Honda Civic XI (2021-2024) Computer data lines circuit, sedan

AUTOMATIC LIGHTING CONTROL UNIT-SENSOR BLK WIRE BLU WIRE CENTER JUNCTION BOX A CLIMATE CONTROL UNIT DATA LINK CONNECTOR (DLC) DRIVER'S JUNCTION BOX B FRONT SEAT HEATER CONTROL UNIT FUSE 19 FUSE HOLDER A GRY WIRE HOT AT ALL TIMES LEFT HEADLIGHT LEFT SIDE BSI RADAR UNIT LT BLU WIRE OPTION CONNECTOR (HAC) PNK WIRE POWER WINDOW MASTER SWITCH PPL RED WIRE RELAY CONTROL MODULE RIGHT END OF DASH) RIGHT HEADLIGHT RIGHT SIDE BSI RADAR UNIT TAN WIRE THERMAL JOINT 7 THERMAL JOINT 8 UNDER-HOOD FUSE/RELAY BOX WHT WIRE WIRELESS CHARGER YEL WIRE

AUDIO UNIT BLK WIRE BLU WIRE BODY CONTROL MODULE (LEFT END OF DASH) BRN WIRE CENTER JUNCTION BOX D FUSE 11 FUSE 25 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ LT BLU WIRE LT GRN WIRE MULTIPURPOSE CAMERA UNIT PARKING, BACKUP SENSOR CONTROL UNIT PNK WIRE PPL RED WIRE TAN WIRE UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE

12 VOLT BATTERY SENSOR 2.0L ACTIVE SOUND CONTROL UNIT ALTERNATOR AUDIO REMOTE- HFL SWITCH BLU WIRE CABLE REEL CENTER JUNCTION BOX E CVT DC-DC CONVERTER DRIVER'S JUNCTION BOX C FRONT PASSENGER'S POWER WINDOW SWITCH GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE M/T MOONROOF MOTOR/ CONTROL UNIT PNK 2.0L PNK WIRE PNK WIRE PPL RED WIRE W/ MOONROOF W/O MOONROOF WHT WIRE WINDSHIELD WIPER CONTROL UNIT/MOTOR YEL WIRE

2.0L BLU WIRE BRN WIRE CENTER JUNCTION BOX B CVT ELECTRIC OIL PUMP ELECTRIC VACUUM PUMP CONTROL UNIT EPS MOTOR/ CONTROL UNIT GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE M/T PNK WIRE PPL RED WIRE SRS UNIT TRANSMISSION CONTROL MODULE VSA MODULATOR CONTROL UNIT WHT WIRE YEL WIRE
