Car Wiring Diagrams for Multipurpose camera circuit, sedan for Honda Civic X (2015-2021)

32 BIT MICROPROCESSOR ACC COMBINATION SWITCH BLK WIRE BLU WIRE BRN WIRE CABLE REEL (UPPER STEERING COLUMN) CMBS OFF SWITCH CMBS OFF SWITCH/RDM SWITCH COMPUTER DATA LINES SYSTEM F-CAN H F-CAN L F-CAN TRANSCEIVER FUSE 24 FUSE 4 FUSE 5 FUSE 7 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES LKAS SWITCH LT BLU WIRE LT GRN WIRE MILLIMETER WAVE RADAR UNIT MULTIPURPOSE CAMERA UNIT PNK WIRE RDM SWITCH RED WIRE UNDER-DASH FUSE/RELAY BOX WARNING DRIVING CIRCUIT WHT WIRE YEL WIRE
