Honda Civic X (2015-2021) wht Wiring diagrams
This page contains all the electrical diagrams for the component. wht, in which he is found in the car Honda Civic X (2015-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram wht (151 of 242)
AUDIO UNIT (W/O NAVIGATION) AUDIO- NAVIGATION UNIT (W/ NAVIGATION)
BACKUP LIGHT SWITCH (M/T)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EX, EXLN, CVT SPORT ONLY
FUSE 18
FUSE 3-2
FUSE 3-3
FUSE 34
FUSE 5
FUSE 7
FUSE 8
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT FRONT WHEEL SPEED SENSOR
LEFT REAR WHEEL SPEED SENSOR
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK WIRE
PPL
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR WHEEL SPEED SENSOR
UNDER- DASH FUSE/ RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/ ADAPTIVE DAMPER SYSTEM W/O ADAPTIVE DAMPER SYSTEM
W/ KEYLESS ACCESS SYSTEM
W/O KEYLESS ACCESS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, hatchback (1 of 3) -> WHT WIRE
Wiring diagram wht (152 of 242)
APPLY SWITCH
AUTOMATIC BRAKE HOLD SWITCH
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE FLUID LEVEL SWITCH
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CLUTCH PEDAL STROKE SENSOR
COMPUTER DATA LINES SYSTEM
ELECTRIC PARKING BRAKE SWITCH
GRN WIRE
GRY WIRE
LEFT REAR ELECTRIC PARKING BRAKE ACTUATOR
LT BLU WIRE
LT GRN WIRE
M/T
NCA WIRE
PNK WIRE
PPL
RED WIRE
RELAY CIRCUIT BOARD
RELEASE SWITCH
RIGHT REAR ELECTRIC PARKING BRAKE ACTUATOR
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
W/ KEYLESS ACCESS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, sedan (2 of 3) -> WHT WIRE
Wiring diagram wht (153 of 242)
2.0L
AUDIO UNIT
AUDIO- NAVIGATION UNIT
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
CENTER DISPLAY UNIT
CMBS OFF SWITCH/ RDM SWITCH
COMBINATION LIGHT SWITCH
COUPE, SEDAN W/O NAVIGATION
CVT CLUTCH PRESSURE CONTROL SOLENOID VALVE
CVT DRIVE PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT DRIVEN PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT LOCK-UP CLUTCH CONTROL SOLENOID VALVE
DATA LINK CONNECTOR (DLC)
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR OUTER HANDLE
DRIVER'S POWER WINDOW MOTOR
FRONT ACCESSORY POWER SOCKET RELAY
FRONT SEAT HEATER RELAY
GAUGE CONTROL MODULE
GRN WIRE
MOONROOF CONTROL UNIT/ MOTOR
ORG/ WIRE
POWER DOOR LOCK RELAY (DOOR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER WINDOW MASTER SWITCH
RED WIRE
SEDAN W/ NAVIGATION
SHIFT SOLENOID VALVE B
STEREO AMPLIFIER
TRUNK LID OPENER SWITCH
TRUNK LID RELEASE ACTUATOR RELAY
UNDER-DASH FUSE/RELAY BOX
VSA OFF SWITCH
VSA/ TPMS OFF SWITCH
W/ KEYLESS ACCESS SYSTEM
W/ NAVIGATION
W/O KEYLESS ACCESS SYSTEM
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit, coupe (3 of 5) -> WHT WIRE
Wiring diagram wht (154 of 242)
2.0L TURBO
AUDIO UNIT
AUDIO- NAVIGATION UNIT
BLK WIRE
BODY CONTROL MODULE
CENTER DISPLAY UNIT
CMBS OFF SWITCH/ RDM SWITCH
CVT CLUTCH PRESSURE CONTROL SOLENOID VALVE
CVT DRIVE PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT LOCK-UP CLUTCH CONTROL SOLENOID VALVE
DATA LINK CONNECTOR (DLC)
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR OUTER HANDLE
DRIVER'S POWER WINDOW MOTOR
FRONT ACCESSORY POWER SOCKET RELAY
FRONT SEAT HEATER RELAY
GAUGE CONTROL MODULE
KEYLESS BUZZER
LEFT POWER MIRROR
ORG/ WIRE
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
RIGHT BACKUP LIGHT
RIGHT BRAKE LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAIL LIGHT
SHIFT SOLENOID VALVE B
STEREO AMPLIFIER
TAILGATE RELEASE ACTUATOR RELAY
UNDER-DASH FUSE/RELAY BOX
VSA OFF SWITCH
VSA/TPMS OFF SWITCH
W/ KEYLESS ACCESS SYSTEM
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit, hatchback (3 of 5) -> WHT WIRE
Wiring diagram wht (155 of 242)
2.0L
AUDIO UNIT
AUDIO- NAVIGATION UNIT
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
CENTER DISPLAY UNIT
CMBS OFF SWITCH/ RDM SWITCH
COMBINATION LIGHT SWITCH
COUPE, SEDAN W/O NAVIGATION
CVT CLUTCH PRESSURE CONTROL SOLENOID VALVE
CVT DRIVE PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT DRIVEN PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT LOCK-UP CLUTCH CONTROL SOLENOID VALVE
DATA LINK CONNECTOR (DLC)
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR OUTER HANDLE
DRIVER'S POWER WINDOW MOTOR
FRONT ACCESSORY POWER SOCKET RELAY
FRONT SEAT HEATER RELAY
GAUGE CONTROL MODULE
GRN WIRE
MOONROOF CONTROL UNIT/ MOTOR
ORG/ WIRE
POWER DOOR LOCK RELAY (DOOR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER WINDOW MASTER SWITCH
RED WIRE
SEDAN W/ NAVIGATION
SHIFT SOLENOID VALVE B
STEREO AMPLIFIER
TRUNK LID OPENER SWITCH
TRUNK LID RELEASE ACTUATOR RELAY
UNDER-DASH FUSE/RELAY BOX
VSA OFF SWITCH
VSA/ TPMS OFF SWITCH
W/ KEYLESS ACCESS SYSTEM
W/ NAVIGATION
W/O KEYLESS ACCESS SYSTEM
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit, sedan (3 of 5) -> WHT WIRE
Wiring diagram wht (156 of 242)
AUTO AUTO CLOSE OPEN
AUTO CLOSE
AUTO OPEN
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
CLOSE RELAY
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
COUPE, SEDAN HATCHBACK
DRIVER'S DOOR KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR SWITCH
FUSE 19
GRN WIRE
GRY WIRE
HALL SENSOR
HOT AT ALL TIMES
KEY
LOCK
LT GRN WIRE
MAP LIGHT SWITCH
MOONROOF CONTROL UNIT/MOTOR (RIGHT FRONT OF ROOF)
MOONROOF SWITCH
MOTOR
OFF CLOSE
OFF OPEN CLOSE
OPEN RELAY
PASSENGER'S DOOR SWITCH
PNK WIRE
POWER WINDOW MASTER SWITCH
POWER WINDOWS SYSTEM
PPL
RED WIRE
TAN WIRE
TILT SWITCH
UNDER-DASH FUSE/RELAY BOX
UNLOCK
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> WHT WIRE
Wiring diagram wht (160 of 242)
1.5L TURBO (OR PPL)
2 HATCHBACK
2.0L
2.0L 1.5L TURBO
APP SENSOR
APP SENSOR A
APP SENSOR B
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPE, SEDAN
DRIVER'S JUNCTION C
EXCEPT HATCHBACK W/ HONDA SENSING,
FUSE 2
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
GRY WIRE
HATCHBACK
HATCHBACK W/ HONDA SENSING, SPORT TOURING, TYPE-R
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT W/
KEY INTERLOCK SOLENOID
KEY-IN SWITCH
LT BLU WIRE
PARK PIN SWITCH PARK PIN SWITCH/SHIFT LOCK SOLENOID
PCM
PNK WIRE
PPL
PPL 2.0L
RELAY CIRCUIT BOARD BRAKE LIGHT RELAY
SHIFT LOCK SOLENOID
SHIFT POSITION INDICATOR
SPORT TOURING, TYPE-R
STEERING LOCK
TAN WIRE
THERMAL JOINT 3 (2.0L) THERMAL JOINT 1 (1.5L TURBO)
TOP OF TRANSMISSION)
TRANSMISSION CONTROL MODULE
TRANSMISSION RANGE SWITCH
TRANSMISSIONS CONTROL SYSTEM
UNDER- DASH FUSE/ RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/ KEYLESS ACCESS SYSTEM
W/O KEYLESS ACCESS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> WHT WIRE
