Honda Civic X (2015-2021) w/ keyless access system w/o keyless access system coupe, sedan hatchback Wiring diagram
This page shows the only wiring diagram for the component.w/ keyless access system w/o keyless access system coupe, sedan hatchback, which is found in the car Honda Civic X (2015-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ keyless access system w/o keyless access system coupe, sedan hatchback (1 of 1)
0) LOW 1) HIGH 2) PASS
0) OFF
0) OFF 1) PARK 2) AUTO 3) HEAD
1) ON
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
DIMMER/ FLASH-TO- PASS SWITCH
DIMMING CIRCUIT
FOG LIGHT RELAY
FRONT FOG LIGHT INDICATOR
FRONT FOG LIGHT SWITCH
FUSE 25
FUSE 26
FUSE 28
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEADLIGHT LOW BEAM RELAY
HEADLIGHT SWITCH
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN ON OR START
LEFT FOG LIGHT
LIGHTS ON IND
LT BLU WIRE
PNK WIRE
PPL
RED WIRE
RIGHT FOG LIGHT
STABILIZER CIRCUIT
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY HOLDER A
W/ KEYLESS ACCESS SYSTEM W/O KEYLESS ACCESS SYSTEM COUPE, SEDAN HATCHBACK
W/ LED
W/O LED
WARNING DRIVE CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit (1 of 2) -> W/ KEYLESS ACCESS SYSTEM W/O KEYLESS ACCESS SYSTEM COUPE, SEDAN HATCHBACK
