Honda Civic X (2015-2021) w/ can gateway w/o can gateway 1.5l turbo 2.0l turbo Wiring diagram
This page shows the only wiring diagram for the component.w/ can gateway w/o can gateway 1.5l turbo 2.0l turbo, which is found in the car Honda Civic X (2015-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ can gateway w/o can gateway 1.5l turbo 2.0l turbo (1 of 1)
ADAPTIVE DAMPER CONTROL UNIT
BLU WIRE
BRN WIRE
CVT
DRIVER'S DOOR
EPS CONTROL UNIT
F-CAN A JUNCTION (UPPER RIGHT END OF DASH)
GRN WIRE
LT GRN WIRE
NO. 1
NO. 2
PNK WIRE
RED (OR GRN) WIRE
RED WIRE
TRANSMISSION CONTROL MODULE
VSA MODULATOR CONTROL UNIT
W/ CAN GATEWAY W/O CAN GATEWAY 1.5L TURBO 2.0L TURBO
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit, hatchback (3 of 3) -> W/ CAN GATEWAY W/O CAN GATEWAY 1.5L TURBO 2.0L TURBO
