Honda Civic X (2015-2021) up/ right Wiring diagrams
This page contains all the electrical diagrams for the component. up/ right, in which he is found in the car Honda Civic X (2015-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
up/ right wiring diagram (1 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL UNIT)
DEFOGGER SYSTEM
DOWN RIGHT
DOWN/ LEFT
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 15
FUSE 9
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
LANE WATCH CAMERA
LEFT
LEFT POWER MIRROR
LEFT/ RIGHT MOTOR
LT BLU WIRE
LT GRN WIRE
MOONROOF CONTROL UNIT/ MOTOR
NAVIGATION SYSTEM
ORG/ WIRE
PNK WIRE
POWER MIRROR DEFOGGER
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RIGHT
RIGHT LEFT
RIGHT POWER MIRROR
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UP LEFT
UP/ DOWN MOTOR
UP/ RIGHT
W/ HEATED MIRRORS
W/ MOONROOF
W/O HEATED MIRRORS
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit, coupe -> UP/ RIGHT
