Honda Civic X (2015-2021) under-hood fuse/ relay holder a Wiring diagrams
This page contains all the electrical diagrams for the component. under-hood fuse/ relay holder a, in which he is found in the car Honda Civic X (2015-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram under-hood fuse/ relay holder a (1 of 2)
A/C COMPRESSOR CLUTCH RELAY
ALTERNATOR
AUDIO REMOTE- HFL SWITCH
AUDIO UNIT
AUDIO- NAVIGATION UNIT
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
CABLE REEL
CAN GATEWAY
CENTER DISPLAY UNIT
DATA LINK CONNECTOR (DLC)
FOG LIGHT RELAY
FROM FUSE 1-7 (DIAGRAM 1 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 6)
FUSE 18
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 3-1
FUSE 3-2
FUSE 3-3
FUSE 3-4
FUSE 3-5
FUSE 3-6
GAUGE CONTROL MODULE
GRN WIRE
HORN RELAY
IMMOBILIZER KEYLESS CONTROL UNIT
INTERIOR LIGHTS CUT RELAY
LT BLU WIRE
POWER WINDOW MASTER SWITCH
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY CIRCUIT BOARD
STARTER CUT RELAY 1
STEREO AMPLIFIER
TO BATTERY SENSOR (DIAGRAM 1 OF 6)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 6)
TO WIRELESS CHARGER (DIAGRAM 5 OF 6)
UNDER-HOOD FUSE/ RELAY HOLDER A
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
VSA MODULATOR CONTROL UNIT
W/ NAVIGATION
W/O KEYLESS ACCESS SYSTEM
W/O NAVIGATION
WHT WIRE
Go to component -> Power distribution circuit, coupe (2 of 6) -> UNDER-HOOD FUSE/ RELAY HOLDER A
