Honda Civic X (2015-2021) trunk lid outer handle switch/ license plate light Wiring diagrams
This page contains all the electrical diagrams for the component. trunk lid outer handle switch/ license plate light, in which he is found in the car Honda Civic X (2015-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trunk lid outer handle switch/ license plate light (1 of 9)
2.0L TURBO
AUTOMATIC BRAKE HOLD SWITCH
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPE
COUPE HATCHBACK
DC-DC CONVERTER
EXCEPT 2.0L TURBO
FUSE 18
FUSE 9 8
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HATCHBACK
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
LEFT TURN SIGNAL INDICATOR (LED)
LT GRN WIRE
NO. 2
PCM
PNK WIRE
RED WIRE
RELAY CIRCUIT BOARD
RIGHT TURN SIGNAL INDICATOR (LED)
TAN WIRE
TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
WARNING DRIVING CIRCUIT
WHT WIRE
Go to component -> Exterior lamps circuit, coupe (4 of 4) -> TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
Wiring diagram trunk lid outer handle switch/ license plate light (2 of 9)
2.0L TURBO
AUTOMATIC BRAKE HOLD SWITCH
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPE
COUPE HATCHBACK
DC-DC CONVERTER
EXCEPT 2.0L TURBO
FUSE 18
FUSE 9 8
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HATCHBACK
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
LEFT TURN SIGNAL INDICATOR (LED)
LT GRN WIRE
NO. 2
PCM
PNK WIRE
RED WIRE
RELAY CIRCUIT BOARD
RIGHT TURN SIGNAL INDICATOR (LED)
TAN WIRE
TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
WARNING DRIVING CIRCUIT
WHT WIRE
Go to component -> Exterior lamps circuit, hatchback (4 of 4) -> TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
Wiring diagram trunk lid outer handle switch/ license plate light (3 of 9)
AUTOMATIC BRAKE HOLD SWITCH
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
FUSE 18
FUSE 9
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
LEFT FRONT TURN SIGNAL LIGHT
LEFT POWER MIRROR
LEFT TURN SIGNAL INDICATOR (LED)
LT GRN WIRE
PCM
PNK WIRE
RED WIRE
RELAY CIRCUIT BOARD
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT POWER MIRROR
RIGHT TURN SIGNAL INDICATOR (LED)
TAN WIRE
TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
WARNING DRIVING CIRCUIT
WHT WIRE
Go to component -> Exterior lamps circuit, sedan (3 of 3) -> TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
Wiring diagram trunk lid outer handle switch/ license plate light (4 of 9)
ACC RELAY
AUDIO UNIT
BLK WIRE
BLU WIRE
BRN WIRE
COUPE, SEDAN HATCHBACK
FUSE 1
FUSE 11
FUSE 30
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
GRY WIRE
LEFT "C" PILLAR)
LOCK SWITCH
LT BLU WIRE
LT GRN WIRE
OUTER HANDLE SWITCH
PNK WIRE
PPL
RED WIRE
TAILGATE OUTER HANDLE/ LOCK SWITCH/ LICENSE PLATE LIGHT
TAN WIRE
TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit (2 of 7) -> TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
Wiring diagram trunk lid outer handle switch/ license plate light (5 of 9)
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BRN WIRE
CLIMATE CONTROL UNIT
COUPE
FRONT ACCESSORY POWER SOCKET
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT SEAT HEATER CONTROL UNIT
GRY WIRE
INNER TAILLIGHT
KEYLESS BUZZER
LEFT "C" PILLAR)
LEFT BACKUP LIGHT
LEFT BRAKE LIGHT
LEFT INNER TAILLIGHT
LEFT REAR RELAY HOLDER A
LEFT REAR RELAY HOLDER B
LEFT REAR SEAT HEATER RELAY (HIGH)
LEFT REAR SEAT HEATER RELAY (LOW)
LEFT REAR SEAT HEATER SWITCH
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT
RIGHT BACKUP LIGHT
RIGHT BRAKE LIGHT
RIGHT INNER TAILLIGHT
RIGHT POWER MIRROR
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SEAT HEATER RELAY (HIGH)
RIGHT REAR SEAT HEATER RELAY (LOW)
RIGHT REAR SEAT HEATER SWITCH
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT
SEDAN
SEDAN, COUPE
TRUNK LID LATCH
TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
WIRELESS CHARGER
Go to component -> Ground distribution circuit, coupe (5 of 5) -> TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
Wiring diagram trunk lid outer handle switch/ license plate light (6 of 9)
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BRN WIRE
CLIMATE CONTROL UNIT
COUPE
FRONT ACCESSORY POWER SOCKET
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT SEAT HEATER CONTROL UNIT
GRY WIRE
INNER TAILLIGHT
KEYLESS BUZZER
LEFT "C" PILLAR)
LEFT BACKUP LIGHT
LEFT BRAKE LIGHT
LEFT INNER TAILLIGHT
LEFT REAR RELAY HOLDER A
LEFT REAR RELAY HOLDER B
LEFT REAR SEAT HEATER RELAY (HIGH)
LEFT REAR SEAT HEATER RELAY (LOW)
LEFT REAR SEAT HEATER SWITCH
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT
RIGHT BACKUP LIGHT
RIGHT BRAKE LIGHT
RIGHT INNER TAILLIGHT
RIGHT POWER MIRROR
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SEAT HEATER RELAY (HIGH)
RIGHT REAR SEAT HEATER RELAY (LOW)
RIGHT REAR SEAT HEATER SWITCH
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT
SEDAN
SEDAN, COUPE
TRUNK LID LATCH
TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
WIRELESS CHARGER
Go to component -> Ground distribution circuit, sedan (5 of 5) -> TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
Wiring diagram trunk lid outer handle switch/ license plate light (7 of 9)
ADAPTIVE DAMPER CONTROL UNIT
AMBIENT LIGHT
AUDIO REMOTE- HFL SWITCH
AUTOMATIC BRAKE HOLD SWITCH
BLU WIRE
BRN WIRE
CABLE REEL
CENTER DISPLAY UNIT
CLIMATE CONTROL PANEL
CMBS OFF/ RDM SWITCH
COUPE
DRIVER'S JUNCTION
ECON SWITCH
ELECTRIC PARKING BRAKE SWITCH
FROM UNDER- HOOD FUSE/ RELAY BOX (DIAGRAM 1 OF 6)
FROM UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 6)
FRONT PASSENGER'S AIR BAG ON/OFF INDICATOR
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FUSE 31
FUSE 32
FUSE 33
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
INNER TAILLIGHT
LEFT "C" PILLAR)
LEFT FRONT PARKING/ DAYTIME RUNNING LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT INNER TAILLIGHT
LEFT REAR RELAY HOLDER A
LEFT REAR RELAY HOLDER B
LEFT REAR SEAT HEATER RELAY (HIGH)
LEFT REAR SEAT HEATER RELAY (LOW)
LEFT REAR SIDE HEATER SWITCH
LEFT TAILLIGHT
LOWER TRAY LIGHT
LT GRN WIRE
MOONROOF SWITCH
OPTION CONNECTOR (FOG LIGHT)
PNK WIRE
PPL
RIGHT FRONT PARKING/ DAYTIME RUNNING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT INNER TAILLIGHT
RIGHT REAR SEAT HEATER RELAY (HIGH)
RIGHT REAR SEAT HEATER RELAY (LOW)
RIGHT REAR SIDE HEATER SWITCH
RIGHT TAILLIGHT
SEDAN
SHIFT POSITION INDICATOR
TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY HOLDER B
UPPER TRAY LIGHT
VSA/TPMS OFF SWITCH
W/ TPMS
W/O TPMS
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, coupe (6 of 6) -> TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
Wiring diagram trunk lid outer handle switch/ license plate light (8 of 9)
ADAPTIVE DAMPER CONTROL UNIT
AMBIENT LIGHT
AUDIO REMOTE- HFL SWITCH
AUTOMATIC BRAKE HOLD SWITCH
BLU WIRE
BRN WIRE
CABLE REEL
CENTER DISPLAY UNIT
CLIMATE CONTROL PANEL
CMBS OFF/ RDM SWITCH
COUPE
DRIVER'S JUNCTION
ECON SWITCH
ELECTRIC PARKING BRAKE SWITCH
FROM UNDER- HOOD FUSE/ RELAY BOX (DIAGRAM 1 OF 6)
FROM UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 6)
FRONT PASSENGER'S AIR BAG ON/OFF INDICATOR
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FUSE 31
FUSE 32
FUSE 33
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
INNER TAILLIGHT
LEFT "C" PILLAR)
LEFT FRONT PARKING/ DAYTIME RUNNING LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT INNER TAILLIGHT
LEFT REAR RELAY HOLDER A
LEFT REAR RELAY HOLDER B
LEFT REAR SEAT HEATER RELAY (HIGH)
LEFT REAR SEAT HEATER RELAY (LOW)
LEFT REAR SIDE HEATER SWITCH
LEFT TAILLIGHT
LOWER TRAY LIGHT
LT GRN WIRE
MOONROOF SWITCH
OPTION CONNECTOR (FOG LIGHT)
PNK WIRE
PPL
RIGHT FRONT PARKING/ DAYTIME RUNNING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT INNER TAILLIGHT
RIGHT REAR SEAT HEATER RELAY (HIGH)
RIGHT REAR SEAT HEATER RELAY (LOW)
RIGHT REAR SIDE HEATER SWITCH
RIGHT TAILLIGHT
SEDAN
SHIFT POSITION INDICATOR
TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY HOLDER B
UPPER TRAY LIGHT
VSA/TPMS OFF SWITCH
W/ TPMS
W/O TPMS
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, sedan (6 of 6) -> TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
Wiring diagram trunk lid outer handle switch/ license plate light (9 of 9)
ACC RELAY
AUDIO UNIT
BLK WIRE
BLU WIRE
BRN WIRE
COUPE, SEDAN
FUSE 1
FUSE 11
FUSE 30
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
GRY WIRE
HATCHBACK
LEFT "C" PILLAR)
LOCK SWITCH
LT BLU WIRE
LT GRN WIRE
OUTER HANDLE SWITCH
PNK WIRE
PPL
RED WIRE
TAILGATE OUTER HANDLE/ LOCK SWITCH/ LICENSE PLATE LIGHT
TAN WIRE
TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit (2 of 7) -> TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
