Honda Civic X (2015-2021) torque converter turbine speed sensor Wiring diagrams
This page contains all the electrical diagrams for the component. torque converter turbine speed sensor, in which he is found in the car Honda Civic X (2015-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram torque converter turbine speed sensor (1 of 2)
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPE, SEDAN
COUPE, SEDAN HATCHBACK
CVT DRIVE PULLEY SPEED SENSOR
CVT DRIVEN PULLEY PRESSURE SENSOR
CVT SPEED SENSOR
GRN WIRE
GRY WIRE
HATCHBACK
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
SHIFT POSITION INDICATOR
TAN WIRE
TORQUE CONVERTER TURBINE SPEED SENSOR
TRANSMISSION FLUID TEMPERATURE SENSOR
WHT WIRE
YEL WIRE
Go to component -> 1.5l turbo, transmission circuit (2 of 3) -> TORQUE CONVERTER TURBINE SPEED SENSOR
Wiring diagram torque converter turbine speed sensor (2 of 2)
32 BIT MICROPROCESSOR
APP SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY)
APP SENSOR A
APP SENSOR B
AT DISPLAY
BACKLIGHT
BLK WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CIRCUIT
COMPUTER DATA LINES SYSTEM
CVT DRIVEN PULLEY PRESSURE SENSOR
CVT SPEED SENSOR
DISPLAY
F-CAN
F-CAN H
F-CAN L
FORCED
FUSE 9
GAUGE CONTROL MODULE
GDC
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INFORMATION
LED DRIVER
LT BLU WIRE
LT GRN WIRE
MULTI-
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
PPL
RED WIRE
SP ODO/TRIP
SPEEDOMETER
TAN WIRE
TFT
TORQUE CONVERTER TURBINE SPEED SENSOR
TRANSCEIVER/
TRANSMISSION FLUID TEMPERATURE SENSOR
TURNING-OFF
UNDER- HOOD FUSE/ RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> 2.0l, transmission circuit (3 of 3) -> TORQUE CONVERTER TURBINE SPEED SENSOR
