Honda Civic X (2015-2021) rfc relay under-hood relay holder a Wiring diagrams
This page contains all the electrical diagrams for the component. rfc relay under-hood relay holder a, in which he is found in the car Honda Civic X (2015-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rfc relay under-hood relay holder a (1 of 2)
2.0L 1.5L TURBO W/ KEYLESS ACCESS SYSTEM W/O KEYLESS ACCESS SYSTEM
BATTERY
BATTERY SENSOR
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
BRN WIRE
DAYTIME RUNNING LIGHT RELAY
EPS CONTROL UNIT
FROM UNDER-HOOD FUSE/ RELAY BOX (DIAGRAM 2 OF 6)
FUSE 1 1
FUSE 1-2 FUSE 1-3
FUSE 1-5
FUSE 1-6
FUSE 1-7
FUSE 10
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE 2-1
FUSE 2-2
FUSE 2-3
FUSE 2-4
FUSE 2-5
FUSE 2-6
FUSE 28
FUSE 29
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
GRY WIRE
HEADLIGHT LOW BEAM RELAY
IGNITION COIL RELAY
INJECTOR RELAY
LT GRN WIRE
PCM
PGM-FI MAIN RELAY 1
PGM-FI SUB- RELAY
PNK WIRE
PPL
RED WIRE
RELAY CIRCUIT BOARD
RFC RELAY UNDER-HOOD RELAY HOLDER A
STARTER
TAILLIGHT RELAY
TAN WIRE
TO FUSE 3-3 (DIAGRAM 2 OF 6)
TO UNDER- DASH FUSE/ RELAY BOX (DIAGRAM 4 OF 6)
TO UNDER- DASH FUSE/ RELAY BOX (DIAGRAM 5 OF 6)
TO UNDER- HOOD FUSE/ RELAY HOLDER B (DIAGRAM 6 OF 6)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 5 OF 6)
TRANSMISSION CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY HOLDER A
UNDER-HOOD FUSE/RELAY HOLDER B
UNDER-HOOD FUSE/RELAY HOLDER B UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
WINDSHIELD WASHER MOTOR RELAY
WINDSHIELD WIPER MOTOR
YEL WIRE
Go to component -> Power distribution circuit, coupe (1 of 6) -> RFC RELAY UNDER-HOOD RELAY HOLDER A
