Honda Civic X (2015-2021) rear window defogger/ mirror defogger switch Wiring diagram
This page shows the only wiring diagram for the component.rear window defogger/ mirror defogger switch, which is found in the car Honda Civic X (2015-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window defogger/ mirror defogger switch (1 of 1)
A/C CONDENSER FAN RELAY
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BRN WIRE
CLIMATE CONTROL PANEL
DRIVER'S JUNCTION C
FUSE 1-3
FUSE 10
FUSE 3-1
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IN-CAR TEMPERATURE SENSOR
LT BLU WIRE
OUTSIDE AIR TEMPERATURE SENSOR
PPL
RADIATOR FAN RELAY
REAR WINDOW DEFOGGER/ MIRROR DEFOGGER SWITCH
RED WIRE
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD RELAY HOLDER C
WHT WIRE
YEL WIRE
Go to component -> 2.0l turbo, automatic a/c circuit (2 of 4) -> REAR WINDOW DEFOGGER/ MIRROR DEFOGGER SWITCH
