Honda Civic X (2015-2021) park pin switch/ shift lock solenoid Wiring diagrams
This page contains all the electrical diagrams for the component. park pin switch/ shift lock solenoid, in which he is found in the car Honda Civic X (2015-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
park pin switch/ shift lock solenoid wiring diagram (1 of 11)
AUDIO UNIT
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CVT CLUTCH PRESSURE CONTROL SOLENOID VALVE
CVT DRIVE PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT DRIVEN PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT LOCK-UP CLUTCH CONTROL SOLENOID VALVE
DRIVER'S JUNCTION C
EXCEPT HATCHBACK W/ HONDA SENSING,
FUSE 1
FUSE 16
FUSE 17 4
FUSE 7
GRN WIRE
GRY WIRE
HATCHBACK ONLY
HATCHBACK W/ HONDA SENSING, SPORT TOURING, TYPE-R
HOT AT ALL TIMES
HOT W/
HOT W/ ACC RELAY ENERGIZED
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
PNK WIRE
PPL
RED WIRE
SHIFT SOLENOID VALVE B
SHIFT SOLENOID VALVE O/P
SPORT TOURING, TYPE-R
TAN WIRE
TRANSMISSION CONTROL MODULE
UNDER- DASH FUSE/ RELAY BOX
UNDER- HOOD FUSE/ RELAY BOX
W/ KEYLESS ACCESS SYSTEM W/O KEYLESS ACCESS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> 1.5l turbo, transmission circuit (1 of 3) -> PARK PIN SWITCH/ SHIFT LOCK SOLENOID
park pin switch/ shift lock solenoid wiring diagram (2 of 11)
1.5L TURBO (EXCEPT M/T)
2.0L (EXCEPT M/T)
BLK WIRE
BLU WIRE
BRN WIRE
COUPE, SEDAN
DRIVER'S DOOR SWITCH
ENGINE START/STOP SWITCH
FRONT PASSENGER'S DOOR SWITCH
GRN WIRE
GRY WIRE
HATCHBACK
HOOD LATCH SWITCH
LEFT REAR DOOR SWITCH
LF ANTENNA
LT BLU WIRE
LT GRN WIRE
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
PPL
RED WIRE
RIGHT REAR DOOR SWITCH
SEDAN
SHIFT POSITION INDICATOR
TOP OF TRANSMISSION)
TRANSMISSION CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit (4 of 7) -> PARK PIN SWITCH/ SHIFT LOCK SOLENOID
park pin switch/ shift lock solenoid wiring diagram (3 of 11)
ADAPTIVE DAMPER CONTROL UNIT
AUDIO REMOTE- HFL SWITCH
AUTOMATIC BRAKE HOLD SWITCH
AUTOMATIC DIMMING INSIDE MIRROR
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
BRN WIRE
CABLE REEL
CAN GATEWAY
CEILING LIGHT
CLIMATE CONTROL PANEL
COUPE
CVT
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT POSITION SENSOR
DRIVER'S VANITY MIRROR LIGHT
ECON SWITCH
ELECTRIC PARKING BRAKE SWITCH
ELECTRIC STEERING LOCK
ENGINE START/ STOP SWITCH
FRONT INDIVIDUAL MAP LIGHT
FUEL TANK UNIT
GRY WIRE
HAZARD WARNING SWITCH
HIGH MOUNT BRAKE LIGHT
IMMOBILIZER KEYLESS CONTROL UNIT
INTEGRATED DRIVE-MODE SWITCH
LEFT POWER MIRROR
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SEAT CUSHION HEATER
MOONROOF SWITCH
MULTIPURPOSE CAMERA UNIT
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
PASSENGER'S VANITY MIRROR LIGHT
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PPL
RIGHT REAR SEAT CUSHION HEATER
SEDAN
SHIFT POSITION INDICATOR
STEERING LOCK
TRUNK LID OPENER SWITCH
W/ KEYLESS ACCESS SYSTEM
W/O ELECTRIC STEERING LOCK
Go to component -> Ground distribution circuit, coupe (4 of 5) -> PARK PIN SWITCH/ SHIFT LOCK SOLENOID
park pin switch/ shift lock solenoid wiring diagram (4 of 11)
A/F SENSOR (SENSOR 1) SHIELD
AUDIO REMOTE- HFL SWITCH
AUTOMATIC BRAKE HOLD SWITCH
AUTOMATIC DIMMING INSIDE MIRROR
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
BRN WIRE
CABLE REEL
CLIMATE CONTROL PANEL
COMBINATION LIGHT SWITCH
DRIVER'S VANITY MIRROR LIGHT
ECON SWITCH
ELECTRICAL PARKING BRAKE SWITCH
ENGINE START/ STOP SWITCH
FRONT INDIVIDUAL MAP LIGHT
HAZARD WARNING SWITCH
HIGH PRESSURE FUEL PUMP SHIELD
IMMOBILIZER KEYLESS CONTROL UNIT
INJECTOR 1 SHIELD
INJECTOR 2 SHIELD
INJECTOR 3 SHIELD
INJECTOR 4 SHIELD
INTEGRATED DRIVE-MODE SWITCH
KNOCK SENSOR SHIELD
MOONROOF MOTOR CONTROL UNIT/MOTOR
MOONROOF SWITCH
MULTI-PURPOSE CAMERA UNIT
PADDLE SHIFTER (-) (DOWN- -SHIFT SWITCH)
PADDLE SHIFTER+ (UP SHIFT SWITCH)
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
PASSENGER'S VANITY MIRROR LIGHT
PCM
POWER WINDOW MASTER SWITCH
SHIFT POSITION INDICATOR
THERMAL JOINT 2
W/ KEYLESS ACCESS SYSTEM
W/O KEYLESS ACCESS SYSTEM
Go to component -> Ground distribution circuit, hatchback (4 of 5) -> PARK PIN SWITCH/ SHIFT LOCK SOLENOID
park pin switch/ shift lock solenoid wiring diagram (5 of 11)
ADAPTIVE DAMPER CONTROL UNIT
AUDIO REMOTE- HFL SWITCH
AUTOMATIC BRAKE HOLD SWITCH
AUTOMATIC DIMMING INSIDE MIRROR
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
BRN WIRE
CABLE REEL
CAN GATEWAY
CEILING LIGHT
CLIMATE CONTROL PANEL
COUPE
CVT
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT POSITION SENSOR
DRIVER'S VANITY MIRROR LIGHT
ECON SWITCH
ELECTRIC PARKING BRAKE SWITCH
ELECTRIC STEERING LOCK
ENGINE START/ STOP SWITCH
FRONT INDIVIDUAL MAP LIGHT
FUEL TANK UNIT
GRY WIRE
HAZARD WARNING SWITCH
HIGH MOUNT BRAKE LIGHT
IMMOBILIZER KEYLESS CONTROL UNIT
INTEGRATED DRIVE-MODE SWITCH
LEFT POWER MIRROR
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SEAT CUSHION HEATER
MOONROOF SWITCH
MULTIPURPOSE CAMERA UNIT
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
PASSENGER'S VANITY MIRROR LIGHT
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PPL
RIGHT REAR SEAT CUSHION HEATER
SEDAN
SHIFT POSITION INDICATOR
STEERING LOCK
TRUNK LID OPENER SWITCH
W/ KEYLESS ACCESS SYSTEM
W/O ELECTRIC STEERING LOCK
Go to component -> Ground distribution circuit, sedan (4 of 5) -> PARK PIN SWITCH/ SHIFT LOCK SOLENOID
park pin switch/ shift lock solenoid wiring diagram (6 of 11)
5 W/ EX-T, EX, LX-P W/ TOURING, HONDA SENSING 6 W/ LX 7 8 W/ LX HONDA SENSING
ADAPTIVE DAMPER CONTROL UNIT
AUDIO UNIT
AUDIO- NAVIGATION UNIT
AUTOMATIC DIMMING INSIDE MIRROR
BACKUP LIGHT SWITCH
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE LIGHT RELAY
BRN WIRE
CAN GATEWAY
CLIMATE CONTROL PANEL
CLIMATE CONTROL UNIT
CMBS OFF/ RDM SWITCH
CONNECTOR
DIODE D
DRIVER'S JUNCTION
ELECTRIC STEERING LOCK
EPS CONTROL UNIT
FROM IGNITION SWITCH (DIAGRAM 4 OF 6)
FRONT PASSENGER'S AIR BAG ON/OFF INDICATOR
FRONT SEAT HEATER CONTROL UNIT
FRONT SEAT HEATER RELAY
FUSE 11
FUSE 17 4
FUSE 21
FUSE 22
FUSE 34
FUSE 35
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GAUGE CONTROL MODULE
IMMOBILIZER KEYLESS CONTROL UNIT
LEFT REAR SEAT HEATER SWITCH
LT BLU WIRE
M/T
MILLIMETER WAVE RADAR UNIT
MULTI-PURPOSE CAMERA UNIT
OPTIONAL
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
PCM
PGM-FI MAIN RELAY 2
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RELAY CIRCUIT BOARD
REVERSE RELAY
RFC UNIT
RIGHT REAR SEAT HEATER SWITCH
SEDAN
SHIFT POSITION INDICATOR
SRS UNIT
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 2 OF 6)
TRANSMISSION CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
Go to component -> Power distribution circuit, coupe (3 of 6) -> PARK PIN SWITCH/ SHIFT LOCK SOLENOID
park pin switch/ shift lock solenoid wiring diagram (7 of 11)
ADAPTIVE DAMPER CONTROL UNIT
AUDIO- NAVIGATION UNIT
AUTOMATIC DIMMING INSIDE MIRROR
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE LIGHT RELAY
BRN WIRE
CLIMATE CONTROL PANEL
CLIMATE CONTROL UNIT
CMBS OFF SWITCH/ RDM SWITCH
CONNECTOR
DIODE D
DRIVER'S JUNCTION A
DRIVER'S JUNCTION C
ELECTRIC STEERING LOCK
EPS CONTROL UNIT
FROM IGNITION SWITCH (DIAGRAM 4 OF 6)
FROM UNDER-DASH RELAY HOLDER (DIAGRAM 4 OF 6)
FRONT PASSENGER'S AIR BAG ON/OFF INDICATOR
FRONT SEAT HEATER CONTROL UNIT
FRONT SEAT HEATER RELAY
FUSE 11
FUSE 17
FUSE 21
FUSE 22
FUSE 3
FUSE 34
FUSE 35
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GAUGE CONTROL MODULE
IMMOBILIZER KEYLESS CONTROL UNIT
LEFT REAR SEAT HEATER SWITCH
LT BLU WIRE
MILLIMETER WAVE RADAR UNIT
MULTIPURPOSE CAMERA UNIT
NO. 2
OPTIONAL
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
PCM
PGM-FI MAIN RELAY 2
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PPL
REAR WINDOW WIPER MOTOR
RED WIRE
RELAY CIRCUIT BOARD UNDER-HOOD FUSE/RELAY BOX
REVERSE RELAY
RFC UNIT
RIGHT REAR SEAT HEATER SWITCH
SHIFT POSITION INDICATOR
SRS UNIT
TO UNDER-DASH RELAY HOLDER (DIAGRAM 4 OF 6)
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 2 OF 6)
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 4 OF 6)
TRANSMISSION CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/ ADAPTIVE DAMPER CONTROL
W/ EX, EXLN, LX,, SPORT
W/ KEYLESS ACCESS SYSTEM W/O KEYLESS ACCESS SYSTEM
W/O ADAPTIVE DAMPER CONTROL
W/O EX, EXLN, LX,, SPORT
W/O KEYLESS ACCESS SYSTEM
WHT WIRE
Go to component -> Power distribution circuit, hatchback (3 of 6) -> PARK PIN SWITCH/ SHIFT LOCK SOLENOID
park pin switch/ shift lock solenoid wiring diagram (8 of 11)
5 W/ EX-T, EX, LX-P W/ TOURING, HONDA SENSING 6 W/ LX 7 8 W/ LX HONDA SENSING
ADAPTIVE DAMPER CONTROL UNIT
AUDIO UNIT
AUDIO- NAVIGATION UNIT
AUTOMATIC DIMMING INSIDE MIRROR
BACKUP LIGHT SWITCH
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE LIGHT RELAY
BRN WIRE
CAN GATEWAY
CLIMATE CONTROL PANEL
CLIMATE CONTROL UNIT
CMBS OFF/ RDM SWITCH
CONNECTOR
DIODE D
DRIVER'S JUNCTION
ELECTRIC STEERING LOCK
EPS CONTROL UNIT
FROM IGNITION SWITCH (DIAGRAM 4 OF 6)
FRONT PASSENGER'S AIR BAG ON/OFF INDICATOR
FRONT SEAT HEATER CONTROL UNIT
FRONT SEAT HEATER RELAY
FUSE 11
FUSE 17 4
FUSE 21
FUSE 22
FUSE 34
FUSE 35
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GAUGE CONTROL MODULE
IMMOBILIZER KEYLESS CONTROL UNIT
LEFT REAR SEAT HEATER SWITCH
LT BLU WIRE
M/T
MILLIMETER WAVE RADAR UNIT
MULTI-PURPOSE CAMERA UNIT
OPTIONAL
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
PCM
PGM-FI MAIN RELAY 2
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RELAY CIRCUIT BOARD
REVERSE RELAY
RFC UNIT
RIGHT REAR SEAT HEATER SWITCH
SEDAN
SHIFT POSITION INDICATOR
SRS UNIT
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 2 OF 6)
TRANSMISSION CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
Go to component -> Power distribution circuit, sedan (3 of 6) -> PARK PIN SWITCH/ SHIFT LOCK SOLENOID
park pin switch/ shift lock solenoid wiring diagram (9 of 11)
1.5L TURBO (EXCEPT M/T)
2.0L (EXCEPT M/T)
BLK WIRE
BLU WIRE
BRN WIRE
COUPE, SEDAN
DRIVER'S DOOR SWITCH
ENGINE START/STOP SWITCH
FRONT PASSENGER'S DOOR SWITCH
GRN WIRE
GRY WIRE
HATCHBACK
HOOD LATCH SWITCH
LEFT REAR DOOR SWITCH
LF ANTENNA
LT BLU WIRE
LT GRN WIRE
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
PPL
RED WIRE
RIGHT REAR DOOR SWITCH
SEDAN
SHIFT POSITION INDICATOR
TOP OF TRANSMISSION)
TRANSMISSION CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit (4 of 7) -> PARK PIN SWITCH/ SHIFT LOCK SOLENOID
park pin switch/ shift lock solenoid wiring diagram (10 of 11)
BATTERY
BATTERY SENSOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
CLUTCH PEDAL POSITION SWITCH A
COUPE, SEDAN
CVT
ENGINE START/STOP SWITCH
FUSE 21
FUSE 30
GRN WIRE
HATCHBACK
LT BLU WIRE
M/T
MAGNETIC SWITCH
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
POWER DISTRIBUTION SYSTEM
RED WIRE
RELAY ENERGIZED
STARTER
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Starting circuit, w/ keyless access system (2 of 2) -> PARK PIN SWITCH/ SHIFT LOCK SOLENOID
Page 1 of 2
1
2
