Honda Civic X (2015-2021) low off auto auto or int or int Wiring diagram
This page shows the only wiring diagram for the component.low off auto auto or int or int, which is found in the car Honda Civic X (2015-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low off auto auto or int or int (1 of 1)
32 BIT MICROPROCESSOR
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
CANADA
COMPUTER DATA LINES SYSTEM
COUPE, SEDAN
CVT
DC-DC CONVERTER
FUSE 11
FUSE 18
FUSE 2-5
FUSE 6
FUSE 7
FUSE 8
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HATCHBACK
HOT AT ALL TIMES
HOT IN ON OR START
INTERMITTENT DWELL TIME CONTROLLER
LOW OFF AUTO AUTO OR INT OR INT
LT BLU WIRE
MIST HIGH
MIST OFF
OF COWL COVER) (UNDER LEFT SIDE
PNK WIRE
PPL
PPL 2.0L NON-TURBO
REAR WIPER MOTOR, RELAY
RED WIRE
RELAY CIRCUIT BOARD
SHIFT POSITION INDICATOR
TOP OF TRANSMISSION)
TRANSMISSION CONTROL MODULE
TRANSMISSION RANGE SWITCH
UNDER- DASH FUSE/ RELAY BOX
UNDER-HOOD RELAY HOLDER B
W/ KEYLESS ACCESS SYSTEM
W/O KEYLESS ACCESS SYSTEM
WARNING DRIVING CIRCUIT
WASH OFF
WASHER FLUID LEVEL IND
WASHER FLUID LEVEL SWITCH
WASHER SWITCH
WHT WIRE
WINDSHIELD WASHER MOTOR
WINDSHIELD WASHER MOTOR RELAY
WINDSHIELD WIPER CONTROL UNIT/MOTOR
WINDSHIELD WIPER SWITCH
WINDSHIELD/REAR WINDOW WASHER MOTOR
WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Front wiper/washer circuit -> LOW OFF AUTO AUTO OR INT OR INT
