Honda Civic X (2015-2021) (left side of Wiring diagram
This page shows the only wiring diagram for the component.(left side of, which is found in the car Honda Civic X (2015-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (left side of (1 of 1)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
CARGO AREA LIGHT
COMPUTER DATA LINES SYSTEM
CVT
DRIVER'S VANITY MIRROR LIGHT
ENGINE COMPT)
FRONT INDIVIDUAL MAP LIGHT
FUSE 18
FUSE 21
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTERIOR LIGHTS CUT RELAY
KEY IN
LEFT "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
M/T
OFF
OFF ON ON
PASSENGER'S VANITY MIRROR LIGHT
PNK WIRE
PPL
RED WIRE
RELAY CIRCUIT BOARD
STEERING LOCK (IF EQUIPPED)
TAILGATE LATCH
TRUNK LID LATCH
TRUNK LIGHT
UNDER-HOOD FUSE/RELAY BOX
W/ VANITY MIRROR LIGHT W/O VANITY MIRROR LIGHT COUPE, SEDAN HATCHBACK
WHT WIRE
YEL WIRE
Go to component -> Entry light timer circuit (1 of 2) -> (LEFT SIDE OF
