Supplemental restraints circuit, except hybrid for Honda Civic VIII facelift (2008-2011)

Supplemental restraints circuit, except hybrid (1 of 4)

Civic Honda VIII facelift (2008-2011): Supplemental restraints circuit, except hybrid (1 of 4)

Get access

2 DOOR, LX, EX EX-L, SI BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DLC (UNDER LEFT SIDE OF DASH) F-CAN+ F-CAN- PTT ODS LFS- RFS- VA VB FRONT PASSENGER'S AIRBAG FUSE FUSE 10 FUSE 9 GND A GND B K-LINE GRN WIRE HOT IN ON OR START LEFT FRONT IMPACT SENSOR (BEHIND LEFT SIDE OF FRONT BUMPER) LFS+ RFS+ LT BLU WIRE MES CONNECTOR MES SCS MICU ODS ODS ORG/ WIRE RED WIRE RIGHT FRONT IMPACT SENSOR (BEHIND RIGHT SIDE OF FRONT BUMPER) SRS SRS UNIT (UNDER MIDDLE OF DASH) UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) WHT WIRE YEL WIRE

Supplemental restraints circuit, except hybrid (2 of 4)

Civic Honda VIII facelift (2008-2011): Supplemental restraints circuit, except hybrid (2 of 4)

Get access

4 DOOR: EX-L AREA NETWORK CONTROLLER BLK WIRE BLU WIRE BRN WIRE CABLE REEL COMPUTER DATA LINES SYSTEM DRIVER'S AIRBAG DRIVER'S SEAT BELT SWITCH 1) UNBUCKLED 2) BUCKLED (UNDER DRIVER'S SEAT) DRIVER'S SIDE AIRBAG INFLATOR (UNDER DRIVER'S SEAT) FAST CONTROLLER AREA NETWORK TRANSCEIVER FRONT PASSENGER'S AIRBAG CUT-OFF INDICATOR FRONT PASSENGER'S SIDE AIRBAG INFLATOR (UNDER FRONT PASSENGER'S SEAT) GAUGE CONTROL MODULE (TACH) GRN (OR BLU) WIRE GRN WIRE GRY WIRE LT GRN WIRE ORG/ WIRE RED WIRE SIDE AIRBAG CUT-OFF IND SRS IND STEERING WHEEL) WARNING DRIVE CIRCUIT WHT (OR GRN) WIRE WHT WIRE YEL (OR BLU) WIRE YEL WIRE

Supplemental restraints circuit, except hybrid (3 of 4)

Civic Honda VIII facelift (2008-2011): Supplemental restraints circuit, except hybrid (3 of 4)

Get access

4 DOOR 4-DOOR 2-DOOR BLK WIRE BLU WIRE BRN WIRE GRN WIRE GRY WIRE LOWER ELEMENT LT GRN WIRE NCA WIRE ODS OPDS SENSOR ORG/ WIRE POW RED WIRE SHIELD GND SIDE ELEMENT UPPER ELEMENT WHT WIRE YEL WIRE

Supplemental restraints circuit, except hybrid (4 of 4)

Civic Honda VIII facelift (2008-2011): Supplemental restraints circuit, except hybrid (4 of 4)

Get access

BLK WIRE BLU WIRE BRN WIRE EX-L EXCEPT 2-DOOR FRBC FRBO LSA+ LSA- RSA+ RSA- GRN WIRE GRY WIRE LEFT SIDE CURTAIN AIRBAG INFLATOR (IN LEFT "C" PILLAR) LEFT SIDE IMPACT LT BLU WIRE LT GRN WIRE LT PPL ORG/ WIRE PNK WIRE PPL REAR SAFING SENSOR (MIDDLE OF FLOOR) RED WIRE RIGHT SIDE CURTAIN AIRBAG INFLATOR (IN RIGHT "C" PILLAR) (IN LEFT "C" PILLAR) RIGHT SIDE IMPACT SIDE OF FLOOR) (4-DOOR) (BASE OF LEFT "B" PILLAR) SRS UNIT (UNDER MIDDLE OF DASH) SSS WHT WIRE YEL WIRE
