Cd player circuit for Honda Civic VIII facelift (2008-2011)
Cd player circuit
14 17 PPL ACC RADIO +B BACK UP
AUDIO UNIT (W/O NAVIGATION) NAVIGATION (W/ NAVIGATION)
BLK WIRE
BRN WIRE
CD CHANGER
FUSE 23
FUSE 35
GA + B
GA +B SUB
GA AUDIO L-
GA AUDIO R-
GA AUDIO SH
GA GND
GA ILL+
GA SYS ON
GA-BUS SH
GA-BUS-
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
LT BLU WIRE
MICU
NCA WIRE
ORG/ WIRE
P-GND
PNK WIRE
PPL
RADIO GND
RED WIRE
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
VBU
WHT WIRE
YEL WIRE
