Backup lamps circuit, a/t for Honda Civic VIII facelift (2008-2011)
Backup lamps circuit, a/t
+2 -1
A/T REVERSE RELAY
BLK WIRE
BRN (OR PPL) WIRE
BRN WIRE
EXCEPT HYBRID
FUSE 10
HOT IN ON OR START
LEFT BACK-UP LIGHT
NAVIGATION SYSTEM (IF EQUIPPED)
OPTION CONNECTOR (USE FOR AUTOMATIC DIMMING INSIDE MIRROR)
PPL
RIGHT BACK-UP LIGHT
TRANS- MISSION RANGE SWITCH (ON TRANS- MISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) MICU
WHT WIRE
WHT/GRN WIRE
