Ima f-can high/low & b-can circuits, hybrid for Honda Civic VIII facelift (2008-2011)
Ima f-can high/low & b-can circuits, hybrid
A/C COMPRESSOR DRIVER (BEHIND IPU LID)
B-CAN
BCM MODULE (BEHIND IPU LID)
CLIMATE CONTROL UNIT
GAUGE CONTROL MODULE (TACH)
HANDSFREELINK CONTROL UNIT (UNDER CENTER CONSOLE)
IMMOBILIZER KEYLESS CONTROL UNIT (IN STEERING COLUMN)
J/C
MCM (BEHIND IPU LID)
NAVIGATION
PCM (LEFT SIDE OF ENG COMPT)
PNK PNK WIRE
PNK WIRE
RED WIRE
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) MICU
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
