Data link connector circuit, gx for Honda Civic VIII facelift (2008-2011)
Data link connector circuit, gx
AUDIO UNIT (OR NAVIGATION UNIT)
BLK WIRE
BRN WIRE
BRN/YEL WIRE
DLC (UNDER LEFT SIDE OF DASH)
ECM/PCM (LEFT SIDE OF ENGINE COMPT)
FUSE 23
GAUGE CONTROL MODULE (TACH)
HANDSFREELINK CONTROL UNIT
HOT AT ALL TIMES
IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN)
INJECTOR CONTROL MODULE (BEHIND RIGHT KICK PANEL)
J/C
K LINE
LT BLU WIRE
MICU
NAVI
NAVIGATION
NAVIGATION UNIT
ORG/ WIRE
RED WIRE
SCS
SRS UNIT (UNDER MIDDLE OF DASH)
TPMS CONTROL UNIT (USA) (UNDER LEFT SIDE OF DASH)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENG COMPT)
VBU
WEN
WHT WIRE
