Forced entry circuit, hybrid for Honda Civic VIII facelift (2008-2011)

BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE DOOR LOCK KNOB DOOR LOCK KNOB SWITCH DOOR LOCK RELAY DRIVER' DOOR LOCK ACTUATOR/KNOB SWITCH (REAR OF DRIVER'S DOOR) DRIVER'S DOOR UNLOCK RELAY FRONT PASSENGER'S DOOR LOCK ACTUATOR/KNOB SWITCH (REAR OF RIGHT FRONT DOOR) FUSE FUSE 10 FUSE 19 FUSE 21 FUSE 25 FUSE FUSE GRN WIRE GRY WIRE HEADLIGHTS SYSTEM HORN RELAY HOT AT ALL TIMES HOT IN ON OR START IG KEY SW VBU VBU B-CAN TRUNK SW RADIO SW AT-P HOOD SW JUNCTION CONNECTOR KEY KEY CYLINDER SWITCH LOCK LOW BEAM HEAD- LIGHT RELAY LT BLU WIRE LT GRN WIRE MICU ORG/ WIRE P-GND P-GND P-GND PASSENGER'S DOOR UNLOCK RELAY PNK PNK ANTI-THEFT SYSTEM WIRE PNK WIRE PPL RED WIRE REM AS LOCK REM AS UNLOCK REM DR LOCK REM DR UNLOCK DRSWRA DRSWRD DRSWAS DRSWDR RIGHT REAR DOOR LOCK ACTUATOR/KNOB SWITCH (REAR OF RIGHT REAR DOOR) S GND TAILLIGHT RELAY TRUNK LID OPENER RELAY UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) UNLOCK WHT WIRE YEL WIRE

AUDIO UNIT (W/O NAVIGATION) NAVIGATION UNIT (IF EQUIPPED) BLK WIRE BLU WIRE BODY COMPUTER SYSTEM BODY CONTROLLER AREA NETWORK TRANSCEIVER BRN WIRE CONTROLLER AREA CONTROLLER AREA NETWORK CONTROLLER DOOR LOCK KNOB SWITCH DRIVER'S DOOR LOCK SWITCH DRIVER'S DOOR SWITCH (ON LEFT "B" PILLAR) FRONT PASSENGER'S DOOR LOCK SWITCH FRONT PASSENGER'S DOOR SWITCH (ON RIGHT "B" PILLAR) FRONT PASSENGER'S POWER WINDOW SWITCH FUSE 12 FUSE 23 GAUGE CONTROL MODULE (SPEEDO) GAUGE CONTROL MODULE (TACH) GRN WIRE GRY WIRE HORN (BEHIND LEFT SIDE OF FRONT BUMPER) HOT AT ALL TIMES IGNITION KEY SWITCH IMMOBILIZER KEYLESS CONTROL UNIT (IN STEERING COLUMN) LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH (REAR OF LEFT REAR DOOR) LEFT REAR DOOR SWITCH (ON LEFT "C" PILLAR) LOCK LT BLU WIRE LT GRN WIRE NETWORK CONTROLLER ORG/ WIRE PNK PNK PNK B-CAN WIRE PNK PNK PNK WIRE PNK WIRE POWER WINDOW MASTER SWITCH PPL RIGHT REAR DOOR SWITCH (ON RIGHT "C" PILLAR) SECURITY HOOD SWITCH (ON ENGINE COMPT HOOD LATCH ASSEMBLY) SECURITY INDICATOR SECURITY INDICATOR BLINKING CIRCUIT TRUNK LID OPENER SOLENOID/ LATCH SWITCH (USA) (MIDDLE OF TRUNK LID) UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) UNLOCK WHT WIRE YEL WIRE YEL/RED WIRE
