Honda Civic VIII facelift (2008-2011) switch up Wiring diagrams

This page contains all the electrical diagrams for the component. switch up, in which he is found in the car Honda Civic VIII facelift (2008-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram switch up (1 of 4)

Wiring diagram switch up for Honda Civic VIII facelift (2008-2011) (1 of 4)

Get access

AUDIO REMOTE SWITCH BLK WIRE BLU WIRE BRN WIRE CABLE REEL (CON B: ON STEERING COLUMN) (CON C: IN STEERING COLUMN) CHANNEL DOWN SWITCH DOWN VOLUME EXCEPT HYBRID GA-NET BUS SH GA-NET BUS- GRN WIRE GRN/RED WIRE GRY WIRE INTERIOR LIGHTS SYSTEM LT BLU WIRE MODE SWITCH NCA WIRE PNK 1 2 3 4 WIRE PNK 7 8 WIRE PNK WIRE RED WIRE RED/BLK WIRE SAT L- SAT R- SH (XM) SIG STEERING WHEEL HFL VOICE CONTROL SWITCH SWITCH SWITCH BACK SWITCH UP SYS ACC TALK SWITCH VOLUME- WHT WIRE XM ANTENNA XM RECEIVER (RIGHT SIDE OF TRUNK)

Go to component -> Navigation circuit, hybrid; 4 door ex, ex-l (2 of 3) -> SWITCH UP

Wiring diagram switch up (2 of 4)

Wiring diagram switch up for Honda Civic VIII facelift (2008-2011) (2 of 4)

Get access

12 13 (OR PNK) WIRE AUDIO REMOTE SWITCH BLK WIRE BLU WIRE BRN WIRE CABLE REEL (CON B: ON STEERING COLUMN) (CON C: IN STEERING WHEEL) CHANNEL DOWN SWITCH DOWN VOLUME GA-NET BUS SH GA-NET BUS- GRN WIRE GRN/RED WIRE GRY WIRE INTERIOR LIGHTS SYSTEM LT BLU WIRE MODE SWITCH NCA WIRE ORG/ WIRE PNK 1 2 3 WIRE PNK 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 WIRE PNK WIRE RED WIRE RED/BLK WIRE SAT L- SAT R- SH (XM) SIG STEERING WHEEL HFL VOICE CONTROL SWITCH SWITCH SWITCH BACK SWITCH UP SYS ACC TALK SWITCH VOLUME- WHT WIRE XM ANTENNA XM ANTENNA LEAD CONNECTOR (LEFT REAR OF ROOF) XM RECEIVER (RIGHT SIDE OF TRUNK) YEL WIRE

Go to component -> Navigation circuit, si; 2 door ex, ex-l (2 of 3) -> SWITCH UP
