Honda Civic VIII facelift (2008-2011) starter solenoid clutch interlock switch starter Wiring diagram

+B RR FOG 2 DOOR, LX, EX EX-L, SI 4 DOOR A/C CONDENSER FAN DIODE FUSE A/C CONDENSER FAN RELAY A/T AUDIO UNIT (EXCEPT NAVIGATION) NAVIGATION UNIT (NAVIGATION) BLK/WHT WIRE BLU/WHT WIRE BRN WIRE DLC ECM/PCM EXCEPT GX FROM FUSE 11 (DIAGRAM 1 OF 5) FROM FUSE 22 (DIAGRAM FUSE 15 1 OF 5) FROM FUSE 23 (DIAGRAM 2 OF 5) FROM FUSE 25 (DIAGRAM 1 OF 5) FROM FUSE 38 FUSE FUSE 11 FUSE 12 FUSE 23 FUSE 26 FUSE 30 FUSE 32 FUSE 33 FUSE 13 FUSE 17 GAUGE CONTROL MODULE (SPEEDO) GAUGE CONTROL MODULE (TACH) GAUGE SRS POWER CONTROL UNIT WINDOW MASTER MODULE SWITCH (SPEEDO) GRN WIRE H/L H/L HI-L LO H/L HI-R HANDSFREELINK NAVIGATION CONTROL UNIT UNIT (NAVIGATION) (NAVIGATION) IMMOBILIZER KEYLESS CONTROL UNIT LEFT HEADLIGHT LEFT REAR POWER WINDOW SWITCH MOONROOF (4 DOOR) CONTROL UNIT LT BLU (OR PNK) WIRE LT GRN WIRE M/T MICU MICU VBU MOONROOF CONTROL UNIT MOONROOF SWITCH ORG/ WIRE P/W TIMER PCM PNK WIRE POWER WINDOW MASTER SWITCH POWER WINDOW RELAY PPL RED (OR BLU) WIRE RED WIRE RIGHT HEADLIGHT RIGHT REAR POWER WINDOW FRONT SWITCH PASSENGER'S (4 DOOR) POWER WINDOW SWITCH SRS STARTER CONTROL RELAY STARTER CUT RELAY STARTER SOLENOID CLUTCH INTERLOCK SWITCH STARTER STS ATP NP SUB RELAY TPMS GAUGE CONTROL CONTROL UNIT MODULE (TACH) (USA) TRANSMISSION RANGE SWITCH UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) UNDER-DASH JUNCTION BOX UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENIGNE COMPT) VBU WHT WIRE
