Honda Civic VIII facelift (2008-2011) shift bcm lock module solenoid Wiring diagram
This page shows the only wiring diagram for the component.shift bcm lock module solenoid, which is found in the car Honda Civic VIII facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shift bcm lock module solenoid (1 of 1)
A/C COMPRESSOR DRIVER
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY
EXCEPT NAVIGATION
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 1 OF 5)
FRONT ACCESSORY POWER SOCKET
FRONT ACCESSORY POWER SOCKET RELAY
FUSE 10
FUSE 22
FUSE 23
FUSE 28
FUSE 29
FUSE 34 (NOT USED) FUSE 35
FUSE 8 (NOT USED)
GRN WIRE
GRY WIRE
IGNITION KEY SWITCH
IGNITION SWITCH
LOCK
LT BLU WIRE
LT GRN WIRE
MICU ACC KEY LOCK
MICU ATP-NP STS
MICU FUSE 2 FUSE 1
MICU FUSE 9
MICU FUSE FUEL PUMP FUEL PUMP
MICU WIPER
ODS VSA
ORG/ WIRE
P/W
PCM
POWER MIRROR SWITCH
PPL
RED WIRE
SHIFT BCM LOCK MODULE SOLENOID
SRS UNIT
STARTER
STARTER CUT RELAY
STARTER SOLENOID
TO FUSE 11 (DIAGRAM 4 OF 5) FUSE 38
TO MICU (DIAGRAM 4 OF 5)
TO UNDER-DASH FUSE/RELAY BOX, FUSE 3 (DIAGRAM 3 OF 5)
TO UNDER-DASH FUSE/RELAY BOX, FUSE 36 (DIAGRAM 3 OF 5)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL (OR BLU) WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit, hybrid (2 of 5) -> SHIFT BCM LOCK MODULE SOLENOID
