Honda Civic VIII facelift (2008-2011) sat l+ sat r+ sat sh gnd ga-net bus sh sys acc +b Wiring diagrams

This page contains all the electrical diagrams for the component. sat l+ sat r+ sat sh gnd ga-net bus sh sys acc +b, in which he is found in the car Honda Civic VIII facelift (2008-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram sat l+ sat r+ sat sh gnd ga-net bus sh sys acc +b (1 of 4)

Wiring diagram sat l+ sat r+ sat sh gnd ga-net bus sh sys acc +b for Honda Civic VIII facelift (2008-2011) (1 of 4)

Get access

+B BACK UP 1 2 3 4 5 USB VBUS USB DATA- USB DATA+ USB GND USB SH 14 13 12 11 10 9 8 7 6 5 4 3 2 1 SAT L- SAT R- 28 30 AC-SO AC-SI 5 4 3 2 1 USB SH USB GND USB DATA+ USB DATA- USB VBUS AC-CLK AMPLIFIER BACK LT- BLK WIRE BLU WIRE BRN WIRE EXCEPT HYBRID GA-NET BUS SH GA-NET BUS- GND GA-NET BUS- GA-NET BUS+ PNK WIRE GPS GPS SH GRN WIRE GRY WIRE HANDS FREE MODULE CIRCUIT LT BLU WIRE MIC SH MIC SIG NAVI GUIDE NAVIGATION UNIT NCA WIRE PNK WIRE RED WIRE SAT L+ SAT R+ SAT SH GND GA-NET BUS SH SYS ACC +B SAT L- SAT R- SAT SH GND SYS ACC USB USB ADAPTER UNIT USB JACK WHT WIRE YEL WIRE

Go to component -> Navigation circuit, hybrid; 4 door ex, ex-l (3 of 3) -> SAT L+ SAT R+ SAT SH GND GA-NET BUS SH SYS ACC +B

Wiring diagram sat l+ sat r+ sat sh gnd ga-net bus sh sys acc +b (2 of 4)

Wiring diagram sat l+ sat r+ sat sh gnd ga-net bus sh sys acc +b for Honda Civic VIII facelift (2008-2011) (2 of 4)

Get access

+B BACK UP 1 2 3 4 5 6 7 8 9 10 11 12 13 14 FL SIG+ SIG SHIELD RL SIG+ FR SIG+ 1 2 3 4 5 USB VBUS USB DATA- USB DATA+ USB GND USB SH 14 13 12 11 10 9 8 7 6 5 4 3 2 1 SAT L- SAT R- 5 4 3 2 1 USB SH USB GND USB DATA+ USB DATA- USB VBUS AMPLIFIER BACK LT- BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER FUSE 17 GA-NET BUS SH GA-NET BUS- GND GA-NET BUS- GA-NET BUS+ PNK WIRE GPS GPS SH GRN WIRE GRY WIRE HANDS FREE MODULE CIRCUIT HOT AT ALL TIMES LEFT REAR SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE MIC SH MIC SIG NAVI GUIDE NAVIGATION UNIT NCA WIRE ORG/ WIRE PNK 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 WIRE PNK WIRE RED WIRE RIGHT REAR SPEAKER RIGHT TWEETER RL SIG- FR SIG- (OR PNK) WIRE RR R SPKR- RR L SPKR- RR SIG+ AMP ON FL SIG- SAT L+ SAT R+ SAT SH GND GA-NET BUS SH SYS ACC +B SAT L- SAT R- SAT SH GND STEREO AMPLIFIER (2-DOOR: UNDER MIDDLE OF DASH) (4-DOOR: UNDER DRIVER'S SEAT) SUBWOOFER SYS ACC UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) USB USB ADAPTER UNIT USB JACK WHT WIRE YEL WIRE

Go to component -> Navigation circuit, si; 2 door ex, ex-l (3 of 3) -> SAT L+ SAT R+ SAT SH GND GA-NET BUS SH SYS ACC +B
