Honda Civic VIII facelift (2008-2011) right inner taillight left license plate light Wiring diagram
This page shows the only wiring diagram for the component.right inner taillight left license plate light, which is found in the car Honda Civic VIII facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right inner taillight left license plate light (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HIGH MOUNT BRAKE LIGHT
INTERIOR LIGHT SYSTEM
JUNCTION CONNECTOR
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT INNER TAILLIGHT
LEFT POWER MIRROR
LEFT REAR SIDE MARKER LIGHT
LEFT SIDE TURN SIGNAL LIGHT
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT INNER TAILLIGHT LEFT LICENSE PLATE LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT POWER MIRROR
RIGHT REAR SIDE MARKER LIGHT
RIGHT SIDE TURN SIGNAL LIGHT
SEAT HEATERS
WHT WIRE
Go to component -> Exterior lamps circuit, hybrid (2 of 2) -> RIGHT INNER TAILLIGHT LEFT LICENSE PLATE LIGHT
