Honda Civic VIII facelift (2008-2011) pnk s-net imoflr Wiring diagram
This page shows the only wiring diagram for the component.pnk s-net imoflr, which is found in the car Honda Civic VIII facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk s-net imoflr (1 of 1)
1 2 3 4 5 6 7 VBU
AUXILIARY UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
B-CAN
BLK WIRE
BLK/YEL WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BRN WIRE
BRN/YEL WIRE
CIRCUIT
COMPUTER DATA LINES SYSTEM
CONTROLLER AREA
DLC (UNDER LEFT SIDE OF DASH)
ENGINE CONTROLS SYSTEM
FUEL PUMP
FUEL TANK UNIT (INSIDE FUEL TANK)
FUSE 19
FUSE 2
FUSE 23
GAUGE CONTROL MODULE (TACH)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IG KEY SW
IGNITION KEY SWITCH
IMMOBILIZER KEYLESS CONTROL UNIT (IN STEERING COLUMN)
IMMOBILIZER SYSTEM INDICATOR
JUNCTION CONNECTOR
LT BLU WIRE
LT GRN WIRE
LT PNK PNK WIRE
MICU
MRLY
NETWORK CONTROLLER
ORG/ WIRE
PARKING BRAKE SWITCH (AT BASE OF PARK LEVER)
PCM (LEFT SIDE OF ENGINE COMPT)
PGM-FI MAIN RELAY 1
PGM-FI MAIN RELAY 2
PNK PNK PNK WIRE
PNK S-NET IMOFLR WIRE
PNK WIRE
S-NET
S-NET B-CAN K-LINE IG KEY SW LG PNK WIRE
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
VBU
WARNING DRIVE CIRCUIT
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Immobilizer circuit, hybrid -> PNK S-NET IMOFLR WIRE
