Honda Civic VIII facelift (2008-2011) left side impact lsi lsi Wiring diagram
This page shows the only wiring diagram for the component.left side impact lsi lsi, which is found in the car Honda Civic VIII facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side impact lsi lsi (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
FRBC FRBO LSA+ LSA- RSA+ RSA-
GRN WIRE
GRY WIRE
LEFT SIDE CURTAIN AIRBAG INFLATOR (IN LEFT "C" PILLAR)
LEFT SIDE IMPACT
LEFT SIDE IMPACT LSI LSI
LT BLU WIRE
LT GRN WIRE
LT PPL
ORG/ WIRE
PNK WIRE
PPL
REAR SAFING SENSOR
RED WIRE
RIGHT SIDE CURTAIN AIRBAG INFLATOR (IN RIGHT "C" PILLAR)
RIGHT SIDE IMPACT
SRS UNIT (UNDER MIDDLE OF DASH)
SSS
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit, hybrid (4 of 4) -> LEFT SIDE IMPACT LSI LSI
