Honda Civic VIII facelift (2008-2011) left front side marker/parking/ turn signal light Wiring diagrams
This page contains all the electrical diagrams for the component. left front side marker/parking/ turn signal light, in which he is found in the car Honda Civic VIII facelift (2008-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front side marker/parking/ turn signal light (1 of 3)
A/T GEAR POSITION INDICATOR PANEL LIGHT
A/T GEAR POSITION INDICATOR PANEL LIGHT/PARK PIN SWITCH (AT)
AMBIEMT LIGHT IN-LINE FUSE
AMBIENT LIGHT SWITCH
AUDIO UNIT (EXCEPT NAVIGATION) NAVIGATION UNIT (NAVIGATION)
BLK WIRE
BLU WIRE
CABLE REEL (EXCEPT DX,
DASH LIGHTS BRIGHTNESS CONTROLLER AND ODOMETER SELECT/RESET SWITCH
DX-VP)
FRONT PASSENGER'S AIRBAG CUT-OFF INDICATOR
FUSE 14
FUSE 15
GRY WIRE
HAZARD WARNING SWITCH
HEATER CONTROL PANEL/ HVAC CONTROL UNIT
HFL-VOICE CRUISE CONTROL CONTROL SWITCH COMBINATION SWITCH (NAVIGATION)
ILLUMI (-)
LEFT BRAKE LIGHT/TAILLIGHT
LEFT FRONT SIDE MARKER/PARKING/ TURN SIGNAL LIGHT
LEFT INNER TAILLIGHT (4 DOOR)
LEFT LICENSE PLATE LIGHT
LEFT REAR SIDE MARKER LIGHT
MICU
POWER MIRROR SWITCH (2-DOOR: EXCEPT USA DX)
RED WIRE
RED/BLK WIRE
RIGHT BRAKE LIGHT/TAILLIGHT
RIGHT FRONT SIDE MARKER/PARKING/ TURN SIGNAL LIGHT
RIGHT INNER TAILLIGHT (4 DOOR)
RIGHT LICENSE PLATE LIGHT
RIGHT REAR SIDE MARKER LIGHT
SMALL RLY
STEERING WHEEL (EXCEPT DX, DX-VP)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
Go to component -> Power distribution circuit, dx models (5 of 5) -> LEFT FRONT SIDE MARKER/PARKING/ TURN SIGNAL LIGHT
Wiring diagram left front side marker/parking/ turn signal light (2 of 3)
4 DOOR
A/T GEAR POSITION INDICATOR
A/T GEAR POSITION INDICATOR PANEL LIGHT/PARK PIN SWITCH (AT)
AMBIENT LIGHT IN LINE FUSE
AMBIENT LIGHT SWITCH
AUDIO UNIT (EXCEPT NAVIGATION) NAVIGATION UNIT (NAVIGATION)
BLK WIRE
BLU WIRE
CABLE REEL
CRUISE AUDIO CONTROL REMOTE COMBINATION SWITCH (USA:EX; SWITCH EX-L,SI)
DASH LIGHTS BRIGHTNESS CONTROLLER AND ODOMETER SELECT/RESET SWITCH
DRIVER'S FRONT SEAT HEATER PASSENGER'S SWITCH SEAT HEATER (EX-L) SWITCH (EX-L)
FRONT PASSENGER'S AIRBAG CUT-OFF INDICATOR
FUSE 14
FUSE 15
GRY WIRE
HAZARD WARNING SWITCH
HEATER CONTROL PANEL/ HVAC CONTROL UNIT
HFL-VOICE CONTROL SWITCH (NAVIGATION)
ILLUMI (-)
LEFT BRAKE LIGHT/TAILLIGHT
LEFT FRONT SIDE MARKER/PARKING/ TURN SIGNAL LIGHT
LEFT INNER TAILLIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR SIDE MARKER LIGHT
MICU
MOONROOF SWITCH
PANEL LIGHT
POWER MIRROR SWITCH
RED WIRE
RED/BLK WIRE
RIGHT BRAKE LIGHT/TAILLIGHT
RIGHT FRONT SIDE MARKER/PARKING/ TURN SIGNAL LIGHT
RIGHT INNER TAILLIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR SIDE MARKER LIGHT
SMALL RLY
STEERING WHEEL)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
VSA OFF SWITCH (EX-L;SI)
Go to component -> Power distribution circuit, except dx models (5 of 5) -> LEFT FRONT SIDE MARKER/PARKING/ TURN SIGNAL LIGHT
Wiring diagram left front side marker/parking/ turn signal light (3 of 3)
A/T GEAR POSITION INDICATOR PANEL LIGHT
A/T GEAR POSITION INDICATOR PANEL LIGHT/ PARK-PIN SWITCH
AMBIENT LIGHT IN LINE FUSE
AMBIENT LIGHT SWITCH
AUDIO CLIMATE UNIT CONTROL UNIT (EXCEPT NAVIGATION) NAVIGATION UNIT (NAVIGATION)
AUDIO REMOTE SWITCH
BLK WIRE
BLU WIRE
CABLE REEL
CRUISE CONTROL COMBINATION SWITCH
DASH LIGHTS BRIGHTNESS CONTROLLER
DRIVER'S SEAT HEATER SWITCH
FRONT PASSENGER'S AIRBAG CUT-OFF INDICATOR
FRONT PASSENGER'S SEAT HEATER SWITCH
FUSE 14
FUSE 15
GRY WIRE
HAZARD WARNING SWITCH
HFL-VOICE CONTROL SWITCH (NAVIGATION)
ILLUMI (-)
LEFT BRAKE LIGHT/TAILLIGHT
LEFT FRONT SIDE MARKER/PARKING/ TURN SIGNAL LIGHT
LEFT INNER TAILLIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR SIDE MARKER LIGHT
MICU
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT BRAKE LIGHT/TAILLIGHT
RIGHT FRONT SIDE MARKER/PARKING/ TURN SIGNAL LIGHT
RIGHT INNER TAILLIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR SIDE MARKER LIGHT
SEAT HEATERS
SMALL RLY
STEERING WHEEL)
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
VSA OFF SWITCH
Go to component -> Power distribution circuit, hybrid (5 of 5) -> LEFT FRONT SIDE MARKER/PARKING/ TURN SIGNAL LIGHT
