Honda Civic VIII facelift (2008-2011) h/l on sw h/l off sw small lt sw combi gdn turn r sw turn l sw Wiring diagram
This page shows the only wiring diagram for the component.h/l on sw h/l off sw small lt sw combi gdn turn r sw turn l sw, which is found in the car Honda Civic VIII facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram h/l on sw h/l off sw small lt sw combi gdn turn r sw turn l sw (1 of 1)
1 3 3 1 (2-DR) (EXCEPT 2-DR)
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (UNDER LEFT SIDE OF DASH)
BRN WIRE
COMBINATION LIGHT SWITCH
EXCEPT GX GX
FUSE 10
FUSE 12
FUSE 15
FUSE 19
FUSE 23
GAUGE CONTROL MODULE (SPEEDO)
GRN WIRE
GRY WIRE
H/L ON SW H/L OFF SW SMALL LT SW COMBI GDN TURN R SW TURN L SW
HAZ SW
HEAD
HEADLIGHT SWITCH
HOT AT ALL TIMES
LEFT
LEFT FRONT SIDE MARKER/ PARKING/ TURN SIGNAL LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TURN SIGNAL INDICATOR
LT GRN WIRE
MICU
OFF HEAD
ORG/ WIRE
P-GND
P-GND P-GND
PARK
PARK OFF
PNK WIRE
RED WIRE
RELAY 2 (SOUNDER) TURN SIGNAL/HAZARD
RIGHT
RIGHT FRONT SIDE MARKER/ PARKING/ TURN SIGNAL LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TURN SIGNAL INDICATOR
S GND
TAILLIGHT RELAY
TURN SIGNAL SWITCH
TURN SIGNAL/ HAZARD FLASHER CIRCUIT
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
VBU
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, except hybrid (1 of 2) -> H/L ON SW H/L OFF SW SMALL LT SW COMBI GDN TURN R SW TURN L SW
