Honda Civic VIII facelift (2008-2011) heater control panel Wiring diagrams
This page contains all the electrical diagrams for the component. heater control panel, in which he is found in the car Honda Civic VIII facelift (2008-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram heater control panel (1 of 3)
BLK WIRE
BLK/WHT WIRE
BLU/RED WIRE
BRN WIRE
DEFOGGER
HEATER CONTROL PANEL
HOT IN ON FUSE 36
LEFT POWER DEFOGGER MIRROR (FRONT OF DRIVER'S DOOR)
LT GRN WIRE
MICU
ORG/ WIRE
POWER MIRROR HEATERS RELAY (EX-L) (CANADA: LX, SPORT, SI)
REAR DEFOGGER CIRCUIT
RELAY POWER CONTROL
RIGHT POWER MIRROR (FRONT OF FRONT PASSENGER'S DOOR)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
Go to component -> Heated mirrors circuit, coupe -> HEATER CONTROL PANEL
Wiring diagram heater control panel (2 of 3)
BLK WIRE
BLK/WHT WIRE
BLU/RED WIRE
BRN WIRE
DEFOGGER
HEATER CONTROL PANEL
HOT IN ON FUSE 36
LEFT POWER DEFOGGER MIRROR (FRONT OF DRIVER'S DOOR)
LT GRN WIRE
MICU
ORG/ WIRE
POWER MIRROR HEATERS RELAY (EX-L) (CANADA: LX, SPORT, SI)
REAR DEFOGGER CIRCUIT
RELAY POWER CONTROL
RIGHT POWER MIRROR (FRONT OF FRONT PASSENGER'S DOOR)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
Go to component -> Heated mirrors circuit, sedan without hybrid -> HEATER CONTROL PANEL
Wiring diagram heater control panel (3 of 3)
2 DOOR, LX, EX EX-L, SI
2 DR: EXCEPT USA DX; 4 DR: EX-L, SI
4 DR 2 DR
:EXCEPT DX,DX-VP
A/T GEAR POSITION IND PANEL LIGHT (A/T)
AMBIENT LIGHT IN-LINE FUSE (IF EQUIPPED)
AND ODOMETER SELECT/RESET SWITCH
AUDIO UNIT (EXCEPT NAVIGATION) NAVIGATION UNIT (NAVIGATION)
BLK WIRE
BOX (UNDER LEFT SIDE OF DASH)
BRIGHTENING SWITCH
BRN WIRE
COMBINATION LIGHT SWITCH
CONTROLLER AREA NETWORK CONTROLLER
DASH LIGHTS BRIGHTNESS CONTROLLER
DIMMING SWITCH
FUSE 10
FUSE 14
FUSE 19
FUSE 23
GAUGE CONTROL MODULE (TACH)
GRY WIRE
H/L ON SW H/L OFF SW SMALL LT SW COMBI GND
HAZARD WARNING SWITCH
HEAD
HEADLIGHT SWITCH
HEATER CONTROL PANEL
HONDA ACCESSORY
HOT AT ALL TIMES
HOT IN ON OR START
HVAC CONTROL
ILLUM
MICU
OFF HEAD
ORG/ WIRE
P-GND P-GND P-GND
PARK
PARK OFF
PNK WIRE
POWER WINDOWS SYSTEM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
S GND
TAILLIGHT RELAY
UNDER- DASH JUNCTION
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
UNIT)
VBU
YEL WIRE
Go to component -> Instrument illumination circuit, except hybrid (1 of 2) -> HEATER CONTROL PANEL
