Honda Civic VIII facelift (2008-2011) fuse 22 fuse 9 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse 22 fuse 9, in which he is found in the car Honda Civic VIII facelift (2008-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse 22 fuse 9 (1 of 2)
+B H/L LO MAIN
+B RR +B RR +B +B FOG D/L FOG SMALL
A/C COMPRESSOR CLUTCH RELAY
A/C CONDENSER FAN RELAY
ABS MODULATOR CONTROL UNIT
ALTERNATOR
BATTERY
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BRAKE PEDAL POSITION HAZARD WARNING SWITCH
CEILING LIGHT
ELECTRICAL LOAD DETECTOR (ELD) UNIT (CANADA M/T: DX-GA)
EPS CONTROL UNIT (CANADA M/T: DX-G)
ETCS CONTROL RELAY
EXCEPT GX GX
FOG LIGHT RELAY (ACCESSORY FOG LIGHTS)
FROM BATTERY (DIAGRAM 1 OF 5)
FROM MULTI-FUSE 1 (DIAGRAM 1 OF 5)
FUSE 10 FUSE 12
FUSE 11 MULTI- FUSE 4
FUSE 13 (NOT FUSE 14 (NOT FUSE 16 (NOT
FUSE 17 FUSE 18
FUSE 18
FUSE 19
FUSE 20
FUSE 21
FUSE 22 FUSE 9
FUSE 24
FUSE 25 FUSE 20 (NOT USED) FUSE 19
FUSE 27
FUSE 31 (NOT USED)
FUSE 5 (NOT
FUSE 6
FUSE 7
FUSE 8
HORN HAZ
IGNITION COIL RELAY
LT BLU WIRE
M/T A/T
MICU +B +B
MICU +B DAY LT/SMART
MICU +B H/L HI MAIN
MICU +B INTR LT
MULTI FUSE 1
MULTI FUSE 2
MULTI FUSE 3
PGM-FI MAIN RELAY 1
RADIATOR FAN RELAY
REAR WINDOW DEFOGGER RELAY
RED WIRE
STARTER
STARTER SOLENOID
SUB-RELAY (DIAGRAM 4 OF 5)
SWITCH
TO IGNITION SWITCH (DIAGRAM 2 OF 5)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 5)
TO UNDER-DASH FUSE/RELAY BOX, FUSE 28, 29 (DIAGRAM 2 OF 5) (NOT USED)
TO UNDER-HOOD FUSE/RELAY BOX, FUSE 23 (DIAGRAM 4 OF 5)
TO UNDER-HOOD FUSE/RELAY BOX, MULTI-FUSE 3 (DIAGRAM 1 OF 5)
TO UNDER-HOOD FUSE/RELAY BOX, MULTI-FUSE 4 (DIAGRAM 1 OF 5)
TPMS CONTROL UNIT (USA)
TRUNK LIGHT
UNDER-DASH FUSE/ RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
USA
USED)
USED) USED) USED)
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Power distribution circuit, dx models (1 of 5) -> FUSE 22 FUSE 9
