Honda Civic VIII facelift (2008-2011) ftp sls nep vssout pnk shift interlock system Wiring diagram
This page shows the only wiring diagram for the component.ftp sls nep vssout pnk shift interlock system, which is found in the car Honda Civic VIII facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ftp sls nep vssout pnk shift interlock system (1 of 1)
AIR CONDITIONING SYSTEM AIR CONDITIONING SYSTEM
APP SENSOR (UNDER LEFT SIDE OF DASH)
BAROMETER SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
CAN-H CAN-L IMACANH IMACANL BKSW COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM SCS
COMPUTER DATA LINES SYSTEM WEN
CRUISE CONTROL SYSTEM
ELD
ELD UNIT
EPS CONTROL UNIT (UNDER RIGHT END OF DASH)
ETCSRLY SUB RLY PNK WIRE
FTP SENSOR
FTP SLS NEP VSSOUT PNK SHIFT INTERLOCK SYSTEM WIRE
FUSE 19
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IMOFLR ACPD APSA APSB
J/C
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PGM-FI SUB- RELAY
PNK ANTI-THEFT SYSTEM WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
STARTING/CHARGING SYSTEM
UNDER- HOOD FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT)
VSV
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.3l (1 of 5) -> FTP SLS NEP VSSOUT PNK SHIFT INTERLOCK SYSTEM WIRE
