Honda Civic VIII facelift (2008-2011) front passenger's power window switch dn Wiring diagram
This page shows the only wiring diagram for the component.front passenger's power window switch dn, which is found in the car Honda Civic VIII facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's power window switch dn (1 of 1)
2 1 2 DOOR 4 DOOR
4 DOOR 2 DOOR 2 8
4-DOOR 2-DOOR
BLK WIRE
BLU WIRE
BRN WIRE
DN UP
DRIVER'S POWER WINDOW MOTOR (IN DRIVER'S DOOR)
DRIVER'S POWER WINDOW SWITCH
FRONT PASSENGER'S POWER WINDOW MOTOR (IN FRONT PASSENGER'S DOOR)
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH DN
FUSE 1
FUSE 26
FUSE 30
FUSE 32 (4 DOOR)
FUSE 33 (4 DOOR)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT REAR POWER WINDOW MOTOR (4 DOOR) (IN LEFT REAR DOOR)
LEFT REAR POWER WINDOW SWITCH (4 DOOR)
LEFT REAR POWER WINDOW SWITCH (4 DOOR) DN
LT BLU WIRE
LT GRN WIRE
MAIN SWITCH
MICU
MULTI-FUSE 4
OFF
OFF DN
OFF OFF UP DN
OFF UP
ON OFF
ORG/ WIRE
POWER WINDOW MASTER SWITCH
POWER WINDOW MOTOR (4 DOOR) (IN RIGHT REAR DOOR)
POWER WINDOW RELAY
PPL
RED WIRE
RIGHT REAR
RIGHT REAR POWER WINDOW SWITCH (4 DOOR)
S GND
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Power windows circuit, dx -> FRONT PASSENGER'S POWER WINDOW SWITCH DN
