Honda Civic VIII facelift (2008-2011) front front front ignition ignition ignition coil no.2 coil no.3 coil no.1 Wiring diagram
This page shows the only wiring diagram for the component.front front front ignition ignition ignition coil no.2 coil no.3 coil no.1, which is found in the car Honda Civic VIII facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front front front ignition ignition ignition coil no.2 coil no.3 coil no.1 (1 of 1)
A/C CONDENSER FAN DIODE
A/C CONDENSER FAN RELAY
BLK/WHT WIRE
BLU WIRE
BRN WIRE
FROM FUSE 10 (DIAGRAM 2 OF 5)
FROM FUSE 11 (DIAGRAM 1 OF 5)
FROM FUSE 18 (DIAGRAM 1 OF 5)
FROM FUSE 25 (DIAGRAM 1 OF 5)
FROM FUSE 38
FRONT FRONT FRONT IGNITION IGNITION IGNITION COIL NO.2 COIL NO.3 COIL NO.1
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 11
FUSE 13 FUSE 14
FUSE 13 FUSE 17
FUSE 15
FUSE 26
FUSE 30 FUSE 32
FUSE 33
FUSE FUSE 12
GAUGE CONTROL MODULE (TACH)
GAUGE SRS CONTROL UNIT MODULE (SPEEDO)
GRN WIRE
H/L +B RR FOG HI-R
H/L H/L HI-L LO
IGNITION COIL RELAY
LEFT HEADLIGHT
LEFT REAR POWER WINDOW SWITCH
LT GRN WIRE
MICU
MICU PW TIMER
PCM
PNK WIRE
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
PPL
REAR FRONT IGNITION IGNITION COIL NO.1 COIL NO.4
REAR IGNITION COIL NO.2
REAR IGNITION COIL NO.3
REAR IGNITION COIL NO.4
RED (OR BLU) WIRE
RED WIRE
RIGHT REAR POWER WINDOW SWITCH
SRS
SUB RELAY
TPMS CONTROL RIGHT HEADLIGHT UNIT (USA)
UNDER HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPARTMENT)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, hybrid (4 of 5) -> FRONT FRONT FRONT IGNITION IGNITION IGNITION COIL NO.2 COIL NO.3 COIL NO.1
