Honda Civic VIII facelift (2008-2011) f-can l ima f-can h computer data lines system Wiring diagram
This page shows the only wiring diagram for the component.f-can l ima f-can h computer data lines system, which is found in the car Honda Civic VIII facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram f-can l ima f-can h computer data lines system (1 of 1)
12 VOLT
A/C COMPRESSOR
A/C COMPRESSOR MOTOR
A/C COMPRESSOR POWER CABLE CONNECTOR (MIDDLE REAR OF
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRAIDED WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM F-CAN H
COMPUTER DATA LINES SYSTEM IMA F-CAN L
ENGINE COMPT)
F-CAN L IMA F-CAN H COMPUTER DATA LINES SYSTEM
FUSE 3
GRN WIRE
GRY WIRE
HI VOLT (-)
HOT IN ON OR START
HOT IN ON OR START UNDER-DASH FUSE/RELAY FUSE 22 BOX (UNDER LEFT END OF DASH)
IGNITION
IMA CAN L
IMA CANH
IMA MOTOR
LT GRN WIRE
MCM (BEHIND IPU LID)
MOTOR ROTOR POSITION SENSOR
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
SCIDB
STATOR MOTOR
SYSTEM
U PHASE
U PHASE MOTOR CURRENT SENSOR
V PHASE
V PHASE MOTOR CURRENT SENSOR
VBU 18 19
W PHASE
W PHASE MOTOR CURRENT SENSOR
WEN
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance ima circuit (3 of 3) -> F-CAN L IMA F-CAN H COMPUTER DATA LINES SYSTEM
