Shift interlock circuit, except hybrid for Honda Civic VIII (2005-2009)
Shift interlock circuit, except hybrid
ATP-P
BKSW ILU ATP-P
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE PEDAL POSITION SWITCH
ECM/PCM (LEFT SIDE OF ENGINE COMPT)
FUSE 10
FUSE 12
FUSE 35
GRN WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
HOUSING)
IGKEY SW
IGNITION KEY SWITCH
KEY INTERLOCK SOLENOID
KEYSOL
LT BLU WIRE
LT GRN WIRE
MULTIPLEX CONTROL UNIT
P-PINSW
PARK PIN SWITCH
PNK WIRE
PPL
RED WIRE
SHIFT LOCK SOLENOID
STOP LIGHT
TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
W/O GX W/ GX
WHT WIRE
WHT/BLK WIRE
YEL WIRE
