Power windows circuit, 2 door: lx, ex, si for Honda Civic VIII (2005-2009)
Power windows circuit, 2 door: lx, ex, si
AUTO DN AUTO UP
BLK WIRE
BLU WIRE
BRN WIRE
DN UP OFF
DRIVER'S POWER WINDOW MOTOR
DRIVER'S POWER WINDOW SWITCH
FRONT PASSENGER'S POWER WINDOW MOTOR
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 10
FUSE 26
FUSE 30
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
MAIN SWITCH ON OFF
MICU
MULTI-FUSE 4
OFF
OFF UP
ORG/ WIRE
P/W TIMER
POWER TOP SYSTEM
POWER WINDOW CONTROL UNIT UP DN (+) (+) PLSA SVCC PLSB SGND
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
PPL PNK WIRE
PULSER
RED WIRE
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
UP DN
UP DN AUTO
WHT WIRE
