Car Wiring Diagrams for Electronic power steering circuit, si for Honda Civic VIII (2005-2009)

BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM CONTROLLER AREA NETWORK ECM (LEFT SIDE OF ENGINE COMPT) EPS CONTROL UNIT (BEHIND RIGHT KICK PANEL) EPS GEAR BOX (UNDER REAR OF ENGINE) EPS INDICATOR EPS MOTOR EPS TORQUE SENSOR (UNDER LEFT SIDE OF ENGINE COMPT) FUSE 10 FUSE 4 GAUGE CONTROL MODULE GRN WIRE GRY WIRE H-U H-V H-W HOT AT ALL TIMES HOT IN ON OR START K LINE LT BLU WIRE LT GRN WIRE MICU MOTOR ANGLE SENSOR (UNDER REAR OF ENGINE) MULTI FUSE 1 NEP PG +B PNK 1 2 3 WIRE PNK WIRE PVF RED WIRE SCS UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) WARNING DRIVE CIRCUIT WHT WIRE WHT/GRN WIRE YEL WIRE
