Honda Civic VIII (2005-2009) front ignition coil 2 Wiring diagram
This page shows the only wiring diagram for the component.front ignition coil 2, which is found in the car Honda Civic VIII (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front ignition coil 2 (1 of 1)
ABS MODULATOR CONTROL UNIT
BATTERY
BCM MODULE
BLK WIRE
BRAIDED WIRE
BRAKE POWER UNIT
BRN WIRE
CKP SENSOR
CMP SENSOR
DATA LINK CONNECTOR
DC-DC CONVERTER
EGR VALVE/ EGR VALVE POSITION SENSOR
ENGINE
EPS CONTROL UNIT EPS TORQUE SENSOR
FRONT IGNITION COIL 1
FRONT IGNITION COIL 2
FRONT IGNITION COIL 3
FRONT IGNITION COIL 4
IMA SYSTEM SHIELD
IMMOBILIZER KEYLESS CONTROL UNIT
IPU MODULE FAN A/C COMPRESSOR DRIVER
KNOCK SENSOR SHIELD
MCM
PCM
REAR IGNITION COIL 1
REAR IGNITION COIL 2 REAR IGNITION COIL 3
ROCKER ARM OIL CONTROL SOLENOID 1 REAR IGNITION COIL 4
ROCKER ARM OIL CONTROL SOLENOID 2
ROCKER ARM OIL PRESSURE SWITCH
SECONDARY
SERVO UNIT
SHIELD
TRANSMISSION
TRANSMISSION RANGE SWITCH
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
YEL WIRE
Go to component -> Ground distribution circuit, hybrid (1 of 3) -> FRONT IGNITION COIL 2
