Honda Civic VIII (2005-2009) dash brightness controller Wiring diagram
This page shows the only wiring diagram for the component.dash brightness controller, which is found in the car Honda Civic VIII (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dash brightness controller (1 of 1)
A/C CONDENSER FAN MOTOR
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR RELAY
BLOWER POWER TRANSISTOR
BRAKE FLUID LEVEL SWITCH
BRN WIRE
DASH BRIGHTNESS CONTROLLER
DATA LINK CONNECTOR
DRIVER'S DOOR
ELD UNIT (USA; CANADA: SI)
EX, SI
FAN CONTROL RELAY
GAUGE CONTROL MODULE (TACH)
LEFT FRONT SIDE MARKER/ PARKING/TURN SIGNAL LIGHT
LEFT HEADLIGHT
LEFT POWER MIRROR POWER MIRROR SWITCH
LOW BEAM HIGH BEAM
MES CONNECTOR
MICU
P-GND
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
RIGHT FRONT SIDE MARKER/ PARKING/TURN SIGNAL LIGHT
RIGHT HEADLIGHT
SEDAN CANADA: EX, LX
SEDAN USA: EX, LX, SI CANADA: DX, DX-G
SRS UNIT
USA: DX
WINDSHIELD WASHER MOTOR
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit, except hybrid (2 of 3) -> DASH BRIGHTNESS CONTROLLER
