Honda Civic VIII (2005-2009) controller area network transceiver Wiring diagrams

This page contains all the electrical diagrams for the component. controller area network transceiver, in which he is found in the car Honda Civic VIII (2005-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram controller area network transceiver (1 of 6)

Wiring diagram controller area network transceiver for Honda Civic VIII (2005-2009) (1 of 6)
Get lifetime access to Honda Civic VIII (2005-2009)

10 11 12 13 14 15 16 17 PPL 11 7 (4 DOOR) (2 DOOR) BLK WIRE BLU WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER BRN WIRE CONTROLLER AREA CONTROLLER AREA NETWORK TRANSCEIVER DRIVER'S DOOR LOCK SWITCH DRIVER'S DOOR SWITCH EXCEPT DX-G FRONT PASSENGER'S DOOR LOCK SWITCH FRONT PASSENGER'S DOOR SWITCH FRONT PASSENGER'S POWER WINDOW SWITCH FUSE 23 FUSE 12 GAUGE CONTROL MODULE (SPEEDO) GAUGE CONTROL MODULE (TACH) GRN (OR BLU) WIRE GRN WIRE GRY WIRE HORN HOT AT ALL TIMES IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN) LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH (4 DOOR) LEFT REAR DOOR SWITCH (4 DOOR) LOCK LT GRN WIRE NETWORK CONTROLLER ORG/ WIRE PNK 5 6 7 8 9 WIRE PNK B-CAN WIRE PNK PNK PNK WIRE PNK WIRE POWER WINDOW MASTER SWITCH PPL RIGHT REAR DOOR SWITCH (4 DOOR) SECURITY INDICATOR SECURITY INDICATOR BLINKING CIRCUIT TRUNK LATCH SWITCH UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) UNLOCK WHT WIRE YEL WIRE

Go to component -> Forced entry circuit, except hybrid canada (2 of 2) -> CONTROLLER AREA NETWORK TRANSCEIVER

Wiring diagram controller area network transceiver (2 of 6)

Wiring diagram controller area network transceiver for Honda Civic VIII (2005-2009) (2 of 6)
Get lifetime access to Honda Civic VIII (2005-2009)

AUDIO UNIT (W/O NAVIGATION) UNIT NAVIGATION (W/ NAVIGATION) BLK WIRE BLU WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER BRN WIRE CONTROLLER AREA CONTROLLER AREA NETWORK TRANSCEIVER DOOR LOCK KNOB SWITCH DRIVER'S DOOR LOCK SWITCH DRIVER'S DOOR SWITCH FRONT PASSENGER'S DOOR LOCK SWITCH FRONT PASSENGER'S DOOR SWITCH FRONT PASSENGER'S POWER WINDOW SWITCH FUSE 23 FUSE 12 GAUGE CONTROL MODULE (SPEEDO) GAUGE CONTROL MODULE (TACH) GRN (OR BLU) WIRE GRN WIRE GRY WIRE HORN HOT AT ALL TIMES IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN) LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH (4 DOOR) LEFT REAR DOOR SWITCH (4 DOOR) LOCK LT BLU WIRE LT GRN WIRE NETWORK CONTROLLER ORG/ WIRE PNK B-CAN WIRE PNK PNK PNK WIRE PNK WIRE POWER WINDOW MASTER SWITCH 11 7 (4 DOOR) (2 DOOR) PPL RIGHT REAR DOOR SWITCH (4 DOOR) SECURITY HOOD SWITCH SECURITY INDICATOR SECURITY INDICATOR BLINKING CIRCUIT TRUNK KEY CYLINDER SWITCH (LX, 4-DOOR EX, 4-DOOR SI) TRUNK LATCH SWITCH (LX) TRUNK LID OPENER SOLENOID/ LATCH SWITCH (EX, SI) UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) UNLOCK WHT WIRE YEL WIRE YEL/RED WIRE

Go to component -> Forced entry circuit, except hybrid usa (2 of 2) -> CONTROLLER AREA NETWORK TRANSCEIVER

Wiring diagram controller area network transceiver (3 of 6)

Wiring diagram controller area network transceiver for Honda Civic VIII (2005-2009) (3 of 6)
Get lifetime access to Honda Civic VIII (2005-2009)

AUDIO UNIT (W/O NAVIGATION) UNIT NAVIGATION (W/ NAVIGATION) BLK WIRE BLU WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER BRN WIRE CANADA CONTROLLER AREA CONTROLLER AREA NETWORK TRANSCEIVER DOOR LOCK KNOB SWITCH DRIVER'S DOOR LOCK SWITCH DRIVER'S DOOR SWITCH FRONT PASSENGER'S DOOR LOCK SWITCH FRONT PASSENGER'S DOOR SWITCH FRONT PASSENGER'S POWER WINDOW SWITCH FUSE 23 FUSE 12 GAUGE CONTROL MODULE (SPEEDO) GAUGE CONTROL MODULE (TACH) GRN WIRE GRY WIRE HORN HOT AT ALL TIMES IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN) KEY LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH LEFT REAR DOOR SWITCH LOCK LT BLU WIRE LT GRN WIRE NETWORK CONTROLLER ORG/ WIRE PNK B-CAN WIRE PNK PNK PNK WIRE PNK WIRE POWER WINDOW MASTER SWITCH PPL RIGHT REAR DOOR SWITCH SECURITY HOOD SWITCH SECURITY INDICATOR SECURITY INDICATOR BLINKING CIRCUIT TRUNK KEY CYLINDER SWITCH TRUNK LATCH SWITCH (CANADA) TRUNK LID OPENER SOLENOID/ LATCH SWITCH (USA) UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) UNLOCK USA WHT WIRE YEL WIRE YEL/RED WIRE

Go to component -> Forced entry circuit, hybrid (2 of 2) -> CONTROLLER AREA NETWORK TRANSCEIVER

Wiring diagram controller area network transceiver (4 of 6)

Wiring diagram controller area network transceiver for Honda Civic VIII (2005-2009) (4 of 6)
Get lifetime access to Honda Civic VIII (2005-2009)

10 11 12 13 14 15 16 17 PPL 11 7 (4 DOOR) (2 DOOR) BLK WIRE BLU WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER BRN WIRE CONTROLLER AREA CONTROLLER AREA NETWORK TRANSCEIVER DRIVER'S DOOR LOCK SWITCH DRIVER'S DOOR SWITCH EXCEPT DX-G FRONT PASSENGER'S DOOR LOCK SWITCH FRONT PASSENGER'S DOOR SWITCH FRONT PASSENGER'S POWER WINDOW SWITCH FUSE 23 FUSE 12 GAUGE CONTROL MODULE (SPEEDO) GAUGE CONTROL MODULE (TACH) GRN (OR BLU) WIRE GRN WIRE GRY WIRE HORN HOT AT ALL TIMES IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN) LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH (4 DOOR) LEFT REAR DOOR SWITCH (4 DOOR) LOCK LT GRN WIRE NETWORK CONTROLLER ORG/ WIRE PNK 5 6 7 8 9 WIRE PNK B-CAN WIRE PNK PNK PNK WIRE PNK WIRE POWER WINDOW MASTER SWITCH PPL RIGHT REAR DOOR SWITCH (4 DOOR) SECURITY INDICATOR SECURITY INDICATOR BLINKING CIRCUIT TRUNK LATCH SWITCH UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) UNLOCK WHT WIRE YEL WIRE

Go to component -> Power door locks circuit, except hybrid canada (2 of 2) -> CONTROLLER AREA NETWORK TRANSCEIVER

Wiring diagram controller area network transceiver (5 of 6)

Wiring diagram controller area network transceiver for Honda Civic VIII (2005-2009) (5 of 6)
Get lifetime access to Honda Civic VIII (2005-2009)

AUDIO UNIT (W/O NAVIGATION) UNIT NAVIGATION (W/ NAVIGATION) BLK WIRE BLU WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER BRN WIRE CONTROLLER AREA CONTROLLER AREA NETWORK TRANSCEIVER DOOR LOCK KNOB SWITCH DRIVER'S DOOR LOCK SWITCH DRIVER'S DOOR SWITCH FRONT PASSENGER'S DOOR LOCK SWITCH FRONT PASSENGER'S DOOR SWITCH FRONT PASSENGER'S POWER WINDOW SWITCH FUSE 23 FUSE 12 GAUGE CONTROL MODULE (SPEEDO) GAUGE CONTROL MODULE (TACH) GRN (OR BLU) WIRE GRN WIRE GRY WIRE HORN HOT AT ALL TIMES IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN) LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH (4 DOOR) LEFT REAR DOOR SWITCH (4 DOOR) LOCK LT BLU WIRE LT GRN WIRE NETWORK CONTROLLER ORG/ WIRE PNK B-CAN WIRE PNK PNK PNK WIRE PNK WIRE POWER WINDOW MASTER SWITCH 11 7 (4 DOOR) (2 DOOR) PPL RIGHT REAR DOOR SWITCH (4 DOOR) SECURITY HOOD SWITCH SECURITY INDICATOR SECURITY INDICATOR BLINKING CIRCUIT TRUNK KEY CYLINDER SWITCH (LX, 4-DOOR EX, 4-DOOR SI) TRUNK LATCH SWITCH (LX) TRUNK LID OPENER SOLENOID/ LATCH SWITCH (EX, SI) UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) UNLOCK WHT WIRE YEL WIRE YEL/RED WIRE

Go to component -> Power door locks circuit, except hybrid usa (2 of 2) -> CONTROLLER AREA NETWORK TRANSCEIVER

Wiring diagram controller area network transceiver (6 of 6)

Wiring diagram controller area network transceiver for Honda Civic VIII (2005-2009) (6 of 6)
Get lifetime access to Honda Civic VIII (2005-2009)

AUDIO UNIT (W/O NAVIGATION) UNIT NAVIGATION (W/ NAVIGATION) BLK WIRE BLU WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER BRN WIRE CANADA CONTROLLER AREA CONTROLLER AREA NETWORK TRANSCEIVER DOOR LOCK KNOB SWITCH DRIVER'S DOOR LOCK SWITCH DRIVER'S DOOR SWITCH FRONT PASSENGER'S DOOR LOCK SWITCH FRONT PASSENGER'S DOOR SWITCH FRONT PASSENGER'S POWER WINDOW SWITCH FUSE 23 FUSE 12 GAUGE CONTROL MODULE (SPEEDO) GAUGE CONTROL MODULE (TACH) GRN WIRE GRY WIRE HORN HOT AT ALL TIMES IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN) KEY LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH LEFT REAR DOOR SWITCH LOCK LT BLU WIRE LT GRN WIRE NETWORK CONTROLLER ORG/ WIRE PNK B-CAN WIRE PNK PNK PNK WIRE PNK WIRE POWER WINDOW MASTER SWITCH PPL RIGHT REAR DOOR SWITCH SECURITY HOOD SWITCH SECURITY INDICATOR SECURITY INDICATOR BLINKING CIRCUIT TRUNK KEY CYLINDER SWITCH TRUNK LATCH SWITCH (CANADA) TRUNK LID OPENER SOLENOID/ LATCH SWITCH (USA) UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) UNLOCK USA WHT WIRE YEL WIRE YEL/RED WIRE

Go to component -> Power door locks circuit, hybrid (2 of 2) -> CONTROLLER AREA NETWORK TRANSCEIVER
