Honda Civic VIII (2005-2009) cd changer Wiring diagrams
This page contains all the electrical diagrams for the component. cd changer, in which he is found in the car Honda Civic VIII (2005-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cd changer (1 of 2)
14 17 PPL ACC RADIO +B BACK UP
AUDIO UNIT (EXCEPT NAVIGATION) NAVIGATION UNIT (USA)
BLK WIRE
BLU WIRE
BRN WIRE
CASSETTE PLAYER/
CD CHANGER
FUSE 35
GRN WIRE
GRY WIRE
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) FUSE 23
HOT IN ACCY OR ON
IN-DASH CD CHANGER
MICU
ORG/ WIRE
P-GND
PPL
PPL W/O CASSETTE PLAYER/
RED WIRE
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
VBU
W/ CASSETTE PLAYER/
WHT WIRE
YEL WIRE
Go to component -> Cd player circuit, except hybrid -> CD CHANGER
Wiring diagram cd changer (2 of 2)
14 17 PPL ACC RADIO +B BACK UP
AUDIO UNIT (EXCEPT NAVIGATION) NAVIGATION UNIT (USA)
BLK WIRE
BRAIDED WIRE
BRN WIRE
BRN/BLK WIRE
CD CHANGER
FUSE 35
GA AUDIO R - GA AUDIO L -
GA BUS+ GA BUS- GA GND
GRN WIRE
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) FUSE 23
HOT IN ACCY OR ON
MICU
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
P-GND
PPL
RED/BLK WIRE
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
VBU
WHT WIRE
Go to component -> Cd player circuit, hybrid -> CD CHANGER
