Honda Civic VIII (2005-2009) body controller network transceiver Wiring diagrams

This page contains all the electrical diagrams for the component. body controller network transceiver, in which he is found in the car Honda Civic VIII (2005-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram body controller network transceiver (1 of 3)

Wiring diagram body controller network transceiver for Honda Civic VIII (2005-2009) (1 of 3)
Get lifetime access to Honda Civic VIII (2005-2009)

BEEPER BLK WIRE BLU WIRE BODY CONTROLLER NETWORK TRANSCEIVER BRIGHTEN SWITCH BRIGHTNESS CONTROLLER BRN WIRE BUMPER) CIRCUIT COMPUTER DATA LINE SYSTEM DASH LIGHTS DIMMING SWITCH DRIVE CIRCUIT ENGINE COOLANT ENGINE COOLANT TEMP. GAUGE BRIGHTNESS CONTROL AND DIMMING CIRCUIT FAST CONTROLLER NETWORK TRANSCEIVER FUEL GAUGE (LCD) FUEL GAUGE BRIGHTNESS CONTROL AND DIMMING CIRCUIT GAUGE CONTROL MODULE (SPEEDO) GAUGE CONTROL MODULE (TACH) GRN WIRE HIGH BEAM DIMMING CIRCUIT HIGH BEAM IND LCD LCD BACK LIGHT LCD BRIGHTNESS CONTROL AND DIMMING CIRCUIT LCD DRIVER LEFT TURN SIGNAL IND LOW FUEL IND LT GRN WIRE MPH/ KM/H SWITCH SENDING MULTI-INFORMATIONAL DISPLAY (MID) UNIT ORG/ WIRE PNK WIRE POINTER BRIGHTNESS CONTROL AND DIMMING CIRCUIT PPL PPL 8 9 RED WIRE RIGHT TURN SIGNAL IND SELECT/ RESET SWITCH SPEEDO SPEEDOMETER (LCD) TEMP. GAUGE (LCD) SPEEDOMETER BRIGHTNESS CONTROL AND DIMMING CIRCUIT TACH TACHOMETER TO A/T GEAR POSITION IND DRIVE CIRCUIT (DIAGRAM 2 OF 2) TO PIN 17 (DIAGRAM 2 OF 2) TURN SIGNAL/ HAZARD RELAY 2 UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) WARNING DRIVE CIRCUIT WASHER FLUID LEVEL SWITCH (CANADA) (BEHIND RIGHT SIDE OF FRONT BUMPER) WHT WIRE YEL WIRE

Go to component -> Instrument cluster circuit, dx, dx-g (1 of 2) -> BODY CONTROLLER NETWORK TRANSCEIVER

Wiring diagram body controller network transceiver (2 of 3)

Wiring diagram body controller network transceiver for Honda Civic VIII (2005-2009) (2 of 3)
Get lifetime access to Honda Civic VIII (2005-2009)

4 DOOR BEEPER BLK WIRE BLU WIRE BODY CONTROLLER NETWORK TRANSCEIVER BRIGHTEN SWITCH BRIGHTNESS CONTROLLER BRN WIRE CIRCUIT COMPUTER DATA LINE SYSTEM CRUISE CONTROL SYSTEM DASH LIGHTS DIMMING SWITCH DRIVE CIRCUIT ENGINE COOLANT ENGINE COOLANT TEMP. GAUGE BRIGHTNESS CONTROL AND DIMMING CIRCUIT FAST CONTROLLER NETWORK TRANSCEIVER FUEL GAUGE (LCD) FUEL GAUGE BRIGHTNESS CONTROL AND DIMMING CIRCUIT GAUGE CONTROL MODULE (SPEEDO) 1 7 (2 DOOR) (4 DOOR) GAUGE CONTROL MODULE (TACH) GRN WIRE GRY WIRE HIGH BEAM DIMMING CIRCUIT HIGH BEAM IND LCD LCD BACK LIGHT LCD BRIGHTNESS CONTROL AND DIMMING CIRCUIT LCD DRIVER LEFT TURN SIGNAL IND LOW FUEL IND LT GRN WIRE LX, EX MPH/ KM/H SWITCH SENDING MULTI-INFORMATIONAL DISPLAY (MID) UNIT ORG/ WIRE PNK WIRE POINTER BRIGHTNESS CONTROL AND DIMMING CIRCUIT PPL PPL TO A/T GEAR POSITION IND DRIVE CIRCUIT (DIAGRAM 2 OF 2) RED WIRE RIGHT TURN SIGNAL IND SECURITY IND (EXCEPT CANADA) SECURITY INDICATOR BLINKING CIRCUIT SELECT/ RESET SWITCH SI, 2 DOOR: LX, EX SPEEDO SPEEDOMETER (LCD) TEMP. GAUGE (LCD) SPEEDOMETER BRIGHTNESS CONTROL AND DIMMING CIRCUIT TACH TACHOMETER TO PIN 17 (DIAGRAM 2 OF 2) TURN SIGNAL/ HAZARD RELAY 2 UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) VSA OFF SWITCH (SI ONLY) (LEFT SIDE OF DASH) WARNING DRIVE CIRCUIT WASHER FLUID LEVEL SWITCH (CANADA) (BEHIND RIGHT SIDE OF FRONT BUMPER) WHT WIRE YEL WIRE

Go to component -> Instrument cluster circuit, ex, lx, si (1 of 2) -> BODY CONTROLLER NETWORK TRANSCEIVER

Wiring diagram body controller network transceiver (3 of 3)

Wiring diagram body controller network transceiver for Honda Civic VIII (2005-2009) (3 of 3)
Get lifetime access to Honda Civic VIII (2005-2009)

BEEPER BLK WIRE BLU WIRE BODY CONTROLLER NETWORK TRANSCEIVER BRIGHTEN SWITCH BRIGHTNESS CONTROLLER BRN WIRE CHARGE/ASSIST GAUGE IMA BATTERY LEVEL GAUGE CIRCUIT COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DASH LIGHTS DIMMING SWITCH DRIVE CIRCUIT ENGINE COOLANT ENGINE COOLANT TEMP. GAUGE BRIGHTNESS CONTROL AND DIMMING CIRCUIT FAST CONTROLLER NETWORK TRANSCEIVER FUEL GAUGE (LCD) FUEL GAUGE BRIGHTNESS CONTROL AND DIMMING CIRCUIT GAUGE CONTROL MODULE (SPEEDO) GAUGE CONTROL MODULE (TACH) GRN WIRE HIGH BEAM DIMMING CIRCUIT HIGH BEAM IND LCD LCD BACK LIGHT LCD DRIVER LEFT TURN SIGNAL IND LOW FUEL IND LT GRN WIRE MPH/ KM/H SWITCH SENDING MULTI-INFORMATIONAL DISPLAY (MID) UNIT ORG/ WIRE PNK WIRE POINTER BRIGHTNESS CONTROL AND DIMMING CIRCUIT PPL PPL 8 9 RED WIRE RIGHT TURN SIGNAL IND SECURITY IND SECURITY INDICATOR BLINKING CIRCUIT SELECT/ RESET SWITCH SPEEDO SPEEDOMETER (LCD) TEMP. GAUGE (LCD) SPEEDOMETER BRIGHTNESS CONTROL AND DIMMING CIRCUIT TACH TACHOMETER TO A/T GEAR POSITION IND DRIVE CIRCUIT (DIAGRAM 2 OF 2) TO PIN 17 (DIAGRAM 2 OF 2) TURN SIGNAL/ HAZARD RELAY 2 UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) WARNING DRIVE CIRCUIT WASHER FLUID LEVEL SWITCH (CANADA) (BEHIND RIGHT SIDE OF FRONT BUMPER) WHT WIRE YEL WIRE

Go to component -> Instrument cluster circuit, hybrid (1 of 2) -> BODY CONTROLLER NETWORK TRANSCEIVER
