Honda Civic VIII (2005-2009) +b sat sys acc Wiring diagram
This page shows the only wiring diagram for the component.+b sat sys acc, which is found in the car Honda Civic VIII (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram +b sat sys acc (1 of 1)
+B SAT SYS ACC
1 2 3 4 5 6 7 8 9 10 11 12 13 14 +B GA-NET SAT SYS ACC BUS SHD GND
1 2 T-ANT SHD (XM)
BLK WIRE
BLU WIRE
BRN WIRE
EXCEPT USA 2-DR EX, SI W/ NAVIGATION
GRN WIRE
GRY WIRE
LT BLU WIRE
NAVIGATION UNIT
NCA WIRE
RED WIRE
SAT BUS+ A SAT BUS- A BUS SHIELD GND PNK WIRE
SAT BUS+ GA-NET SAT BUS- GA-NET GA-NET GND PNK WIRE
SAT R+ SAT L+ SAT R- SAT L- SAT SHIELD GND
SAT R- SAT L-
WHT WIRE
XM ANTENNA
XM RECEIVER
Go to component -> Xm receiver circuit -> +B SAT SYS ACC
